Oxygen Analyzer OMD-625

Oxygen Analyzer OMD-625

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

   OMD-625 Oxygen Analyzer Description
The OMD-625 is a cost-effective online intrinsically safe instrument for measuring oxygen continuously with very little maintenance requirements.  The analyzer is designed for use in Class 1, Division 1 groups B, C, D.  Primary applications for this analyzer include natural gas, landfill, hydrogen production and other industrial applications.

OMD-625 Oxygen Analyze Core oxygen detection technique
The oxygen sensor is based on the galvanic electrochemical fuel cell principal and is manufactured in house under a strict quality procedure.  The sensors are self contained and minimal maintenance is required  no need to clean electrodes or add electrolyte.  The precision sensors offer excellent performance, accuracy and stability while maximizing the expected life.

OMD-625 Oxygen Analyzer Optional Configurations

  • Sample System Add-On Components
  • Bi-Directional RS485 Modbus RTU
  • Extreme Weather Packaging w/ Heater

OMD-625 Oxygen Analyzer Applications
  • Natural Gas Extraction & Pipelines
  • Natural Gas Processing
  • Acid (CO2) Gas Streams
  • Inert, Hydrocarbon, Hydrogen Processing
  • And Many Other Industrial Applications

OMD-625 Oxygen Analyzer Specifications

Accuracy:
< +/-1% Full Scale Range*
Alarms: 2 Configurable Relay Contacts
Analyzer Range: 0 - 10/100/1000/10000ppm/25%
Optional Range 1: 0 - 1%,/5%/10%/25%/100%
Area Classification: Class 1, Div 1, Groups B,C,D
Dimensions: 15.25 x 12.5 x 5.25
Flow: 0.25 - 5.0 SCFH
Gas Connections: 1/4 Compression Tube
Output: Isolated 4 - 20mA or 1 - 5 VDC
Power: 12 - 24 VDC
Pressure: 0.1 - 50 PSIG Inlet, vent to atm
Response Time: T90 in 10 Seconds
Sensor: Precision Fuel Cell
Temperature: -10 to 50 deg C
Warranty Sensor: 12 Months
Warranty Electronics: 12 Months
Weight: 18.5 lbs
*Accuracy at constant conditions
