OPC-N3 PM2.5 Particle Sensor

OPC-N3 PM2.5 Particle Sensor

Application:  other

Market Type:  After Market

Maximum Prodcution Capacity:  3000 Pcs/Month

Delivery Time:  5~7 Work Days

Place of origin:  United Kingdom

Price Terms:  FOB

Delivery Port:  HK

Minimum Order:  1Piece/Pieces

Product Attribute:

Applicationt:

other

Production Description:

OPC-N3 PM2.5 Particle Sensor Schematic Diagram


* PM1 , PM2.5 and PM10
* Reduced power standby mode
* Capability to measure up to 2,000  µ g/m 3
* Onboard temperature and humidity sensor
* SPI interface not included, order code 000-0SPI-00


OPC-N3 PM2.5 Particle Sensor MEASUREMENT
Particle range Spherical equivalent size (based on RI of 1.5, S of 1.65) 0.38 to 40
Size categorisation Number of software bins 24
Sampling interval Histogram period (seconds) 1 to 30
Total flow rate (typical) L/min 1.2
Sample flow rate (typical) mL/min 220
Max particle count rate Particles/second 10,000
Max coincidence probability % concentration at 10 6 particles/L 0.84
% concentration at 500 particles/L 0.24

OPC-N3 PM2.5 Particle Sensor POWER
Measurement mode mA (typical) 175
Standyby mode mA (typical) < 50
Voltage range VDC 4.8 to 5.2
Switch-on transient mW for 1ms < 5000

OPC-N3 PM2.5 Particle Sensor DATA
Digital interface/connections SPI (real-time data and communications)
Micro USB (firmware updates and standalone mode)
Data storage micro-SD (.CSV format) (GB) 16

OPC-N3 PM2.5 Particle Sensor KEY SPECIFICATIONS
Digital interface SPI (Mode 1), USB
Laser classification as enclosed housing Class 1
Temperature range °C -10 to 50
Humidity range % rh (continuous) 0 to 95 (non-condensing)
Weight g < 105

OPC-N3 PM2.5 Particle Sensor
