SBA-20-50 Industrial Spray Booth

Product Attribute:

Power:85KW

Applicationt:

auto

Production Description:

Product Details:

Type	Spray Booths
Power	85KW
External Size	20000X5000X5000MM(LXWXH)
Internal Size	20144X6896X5600MM(LXWXH)
Voltage	As request
Certification	ISO 9000/9001/9004/19011: 2000
Place of Origin	China (Mainland)
Brand Name	Hongtech
Model Number	SBA-20-50

Payment & Shipping Terms:

Price:	Get Latest Price

Detailed Product Description
SBA-20-50(without basement) Spray Booth is an advanced type of industrial spray booth
Industrial Spray Booth

20000-5000-5000(without basement) Spray Booth is an advanced type ofindustrial spray booth which absorbing several technical advantagesfrom domestic and abroad.Excellent design and perfect technology makeour spray booth more suitable to the market's requirements.
Theinner dimension 20000X5000X5000mm is very popular in many countries.Andit's equipped many parts imported parts,like the Italy Rielloburner,Philip lights,etc.We can adjust the size according to customer'sdesires.
CE certification guarantees excellently performance,strong practicabilities,and high economical efficiency.

Technical Data

Inside Dimension	20000X5000X5000MM(LXWXH)
Outside Dimension	20144X6896X5600MM(LXWXH)
Pit	ithout basement. Exhaust air from 2 rows of pit in the ground, dimension of each pit is 18000x840mm(LXW)
Main door	4-folds, 4000X4500MM(WXH), color: white
Personal door	2 units, 700x2000MM(WXH), color: white
Wall panel	4 units supporting steel and 4 units profiled bar beamin the roof to strengthen the room body, wall panel thickness: 70mm,m, tongue and groove structure, 0.476mm color steel withpolystyrene inside, color: white
Lighting	Ceiling lights: 26Unitsx4Pcs=104Pcsx36W, Side lights:8Unitsx4Pcs=72Pcsx36W ,Vertical (left side have 8 units, right sidehave 8 units, rear side have 2 units)
Generator setting	Intake air from side upper direction, exhaust air fromrear side direction, quadrate steel frame, outside is white coatedsteel, inside is galvanized steel.
Intake and exhaust air systems 3 units	3 units intake and exhaust air system in total 6x7.5KWdouble-intake centrifugal fans for intake air, model YDW5.6M, aircapacity is 20000m3/h for each fan
	3x11KW double-intake centrifugal fans for exhaust air, model TAE-710H, belt-drive, air capacity is 36000m3/h for each fan
Heating system 3 units	3pcs Riello RG5S oil burners, Maximum heatproductivity: 780000Kcal/H, 3 pcs stainless steel heat exchangers,3electric dampers from spraying to baking cycle
Filter sy
