Product Attribute:
Output current:21.6A
Applicationt:
auto
Production Description:
Detailed Product Description
GED 1528 Mig/Mag Welding Machine,co2 Welding Machine
4-wheel driving device for feeding welding wire
HONGTECH GED1528 Semi-automatic MIG/MAG Welding Machine is usedfor all the position fast welding of sheet, mid-thick plate and spotwelding. Many used in welding of metallic material such as low steel,low-alloy high strength steel, stainless steel, steel, iron, copper,aluminum, nickel etc. Be equipped with PWM system, high power andsmooth feeding of welding wire are available. With the special functionfor the sheet spot welding (not for long seam welded), regulatingwelding time and space time can relieve the fatigue of the operator'shand and wrist. The equipment is used widely in the steel structure,petroleum chemical industry, auto, shipping and machinery manufacture.
l Unique function for automatic inspection of output current
l Digital display
l Multi-layer bridge commutation
l 4-wheel driving device for feeding welding wire
l Equipped heatable decompression meter
l Electric arc regulation
l High quality weld appearance
Technical Data
|
Parameters
|
Data
|
|
Power Supply
|
380 V ,50Hz
|
|
Max. efficient output current
|
21.6A
|
|
Rated max. Input current
|
16.4A
|
|
No load voltage
|
21-40V
|
|
Welding current
|
35-320A
|
|
Duty cycle
|
35%
|
|
Output current voltage
|
35A / 17V-320A / 30V
|
|
Insulation grade
|
F
|
|
Diameter of centralization corresponding welding rods grade
|
Low carbon solid steel welding wire with diameter of 0.8-1.0-1.2?
|
|
Voltage regulation stage
|
10
|
