SBA500 Spray Booth

Product Attribute:

Power:17.5KW

Height:300mm

Applicationt:

auto

Production Description:

Product Details:

Type	Spray Booths
Power	17.5KW
External Size	7200X3900X2700MM(LXWXH)
Internal Size	7340X5350X3470MM(LXWXH)
Voltage	As requested
Certification	ISO 9000/9001/9004/19011: 2000
Place of Origin	China (Mainland)
Brand Name	Hongtech
Model Number	SBA500

Payment & Shipping Terms:

Price:	Get Latest Price
Minimum Order Quantity:	1 Unit/Units
Payment Terms:	T/T

Detailed Product Description
Spray Booth SBA500 inner dimension 7200*3900*2700mm is very popular in many European countries.And it's equipped many parts

SBA500 Spray Booth is an advanced type of spray booth whichabsorbing several technical advantages from domestic andabroad.Excellent design and perfect technology make our spray boothmore suitable to the market's requirements.
The inner dimension7200*3900*2700mm is very popular in many European countries.And it'sequipped many parts imported parts,like the Italy Riello burner,Philiplights,etc.
CE certification guarantees excellently performance,strong practicabilities,and high economical efficiency.



Technical Data

Inside Dimension	7200X3900X2700MM(LXWXH)
Outside Dimension	7340X5350X3470MM(LXWXH)
Main door	3-fold, 3000X2650MM(WXH)
Personal door	1-fold, 800X2000MM(WXH)
Wall panel	EPS heat preservation panel double skinned ,tongue and grooveconstruction, thickness: 70mm, roof panel: 60mm EPS heat preservationplate
Basement and floor	Complete steel assemble, height:300mm, complete grille, 3pcs of ramp,900X2000MM(WXL)
Lighting	Upper inclined lights:32PcsX36W;Lower lights:2PcsX10unitsX36W;Vertical installation, Illuminance:800Lux
Generator setting type	Back upper intake air, back upper extract air, aluminium alloy frame, coated steel.
Intake fan	1 centrifugal fan,7.5KW,capacity:25000m3/h
Extract fan	1 centrifugal fan,7.5KW,capacity:25000m3/h
Heating system	Riello RG5S oil burner,260000Kcal, Stainless steel heat exchanger,highest temperature 80C, electric damper execute from spraying tobaking cycle
Filter system	Prefilter, high efficiency filter(ceiling filter), floor filter, extract filter
Control system	Spraying, risen-temperature spraying, baking temperature, timesetting, lighting switch, time accumulator, pressure Gauge, emergencystop, failure alarm, temperature control meter
Total power	17.5KW
