Quick Details

• Inner diameter :

  30mm

• Number of Row:

  Single Row

• Bore Size:

  80mm

• Outer Diameter :

  185mm

• Size:

  97mm

• Type:

  Pillow Block Bearing

• Place of Origin:

  Germany

• Samples:

  Free

• Delivery Time:

  15 Days

• Packing:

  Box

• Max. Production Capacity:

  200 Pcs

• Export Ratio:

  41% - 50%

• OE Experience:

  No

Product Name:Export SNV072-F FAG Split Housing

Export SNV072-F FAG Split Housing

Application

Bugatti

Product Description:

FAG SNV072-F-L + 21306 + DH306 a whole set
Type: split plummer block housing with cylindrical bore, for grease and oil lubrication
Seal: double lip seals
d: 30 mm
a: 185 mm
h1: 97 mm
g: 80 mm
Housing M: 2 kgs
Bearing Part No.: 21306
Lock nut: KM6
Tab washer: MB6
Locating ring: FRM 72/7
Double lip seal: DH306
Cover: DKV072
Housing designation: SNV072-F-L

FAG SNV housing is made from flake graphite cast iron EN-GJL-HB215(suffix L). The load carrying capacity is considerably higher than for SN/SNE housings. For particularly high loads, we can supply housing made from spheroidal graphite cast iron, which indicated by the suffix D.
