Quick Details

• Color:

  Black Blue Red Yellow

• Max Lifting:

  29t

• System Pressure:

  16Mpa

• Seal Height:

  1618mm

• Cylinder Capacity:

  59L

• Suitable Van Length:

  5200-5400mm

• Designed Capacity:

  Own Design Manufacture

• Available Capacity:

  120000 Sets / Year

• Core Components:

  Hydraulic Cylinder

• Main Raw Material:

  Steel

Product Name:Telescropic Hydraulic Cylinder For HOWO Dump Truck

Telescropic Hydraulic Cylinder For HOWO Dump Truck

Product Description:

OEM No/Model: TG152

Single-Acting Telescopic Hydraulic Cylinder for Rear Dump Truck

Application
Our hydraulic cylinders are widely used on Dump truck,construction machinery,earthmoving vehicles.general industrial,mining.waste management,etc

Features:
1. Suitale for a wider range of temperature and different working conditions
2. Parker seal kits, good quality.
3. Rod chromeplated, rustproof, hard.
4. Sealing on double ends can substantially reduce the cylinder inner leakage, the lose of vehicle lifting force and the falling possibility of the carriage.
5. Anti-shake patented technology ensures a smooth lifting of the carriage to the biggest angle and
6. Descending buffering patented technology maintains a reasonable range of impact when the carriage descends to the auxiliary girder.

About Us

We produce hydraulic cylinder over 10 years. Now having all kinds of advanced equiments morn than 200 sets, such as: Hole grinding machine made in American, full-fuction CNC machine, computer checking platform and so on.
Single-acting hydraulic cylinder is our superstar production, it is recognised around the world for its good performance.

Model No.	Max Lifting (T)	System Pressure (MPa)	Stroke (mm)	Cylinder Capacity (L)	Suitable Van Length (mm)	Rear Overhang (mm)	Lifting Angle (°)
3TG-E152×3830	29	16	1618	59	5200-5400	800	48°-52°
3TG-E152×4000	29	16	1675	62	5400-5600	800	48°-52°
4TG-E152×4270	29	16	1414	58	5600-5800	800	48°-52°
4TG-E152×4270	29	16	1509	63	5800-6200	800

Hubei Jiaheng Technology & Scinece Co.,ltd located at Yunxian economic development, extremely superior transportation. Our company is keen to develop and produce all kinds of hydraulic system products, hydraulic cylinder set, pump truck hydraulic( arm support and pumpover), truck mounted crane ...[Read More]

Company Profile:

• Main Product:

  Hydraulic Cylinders

• Business Type:

  Manufacturer

• Current Export Market:

  South America, Eastern Europe, Southeast Asia, Mid East, Africa

• Total Annual Sales:

  More than 100,000,000

Factory Profile:

• Number of Employees:

  500 - 1000 People

• Shift:

  2

• Years of OEM Experiences:

  8

• Equipment Name:

  Exclusive CNC lathes, Scraping roller burnishing machines, Deep hole boring machines, CNC cylinder welding machine, Abrasive belt grinding machine

Research & Development:

• Capability for Synchronized Development:

  Develop according to drawing or samples provided by clients?Yes

  Develop 3-D model and prototype according to client's needs?Yes

• Tooling Design:

  Design Internally

• Source of Tooling:

  Made Internally

• Software/Profile:

  Unigraphics, AUTOCAD, Autodesk Inventor, Catia
