Natural rubber compound limits heating-up.
Popular tread design, full ply construction and thick sidewalls.
Tyre Size |
PR |
Tread pattern |
Tread Depth (mm) |
Rim Size |
Tube | Flap | Tyre Dimensions |
Inflation Pressure (kPa) |
Load Capacity/Forklift(kg) | ||||
Max in Service(mm) | 25km/h | 35km/h | |||||||||||
Outer Diameter |
Section Width |
Drive Wheel |
Steer Wheel |
Drive Wheel |
Steer Wheel |
||||||||
5.00-8 | 8 | LQ301 | 10 | 3.00D | 5.00-8 | 5.00-8 | 476 | 143 | 825 | 1235 | 950 | 1190 | 885 |
10 | LQ301 | 10 | 3.00D | 5.00-8 | 5.00-8 | 476 | 143 | 1000 | 1415 | 1090 | 1365 | 1015 | |
18*7-8 (180/70-8) |
16 | LQ301 | 10 | 4.33R | 18*7-8 | 18*7-9 | 471 | 187 | 1000 | 2145 | 1650 | 2065 | 1535 |
18 | LQ301 | 10 | 4.33R | 18*7-8 | 18*7-9 | 471 | 187 | 1050 | 2405 | 1850 | 2315 | 1720 | |
6.00-9 | 10 | LQ301 | 12 | 4.00E | 6.00-9 | 6.00-10 | 540 | 160 | 860 | 1505 | 1275 | 1400 | 1120 |
12 | LQ301 | 12 | 4.00E | 6.00-9 | 6.00-10 | 540 | 160 | 1030 | 1675 | 1415 | 1560 | 1245 | |
7.00-9 | 10 | LQ301 | 13.5 | 5.00S | 7.00-9 | 7.00-9 | 590 | 190 | 860 | 1995 | 1685 | 1850 | 1480 |
21*8-9 (200/75-9) |
14 | LQ301 | 12 | 6.00E | 21*8-9 | 21*8-10 | 546 | 216 | 900 | 2535 | 1950 | 2440 | 1815 |
16 | LQ301 | 12 | 6.00E | 21*8-9 | 21*8-10 | 546 | 216 | 1000 | 2755 | 2120 | 2650 | 1970 | |
6.50-10 | 10 | LQ301 | 13 | 5.00F | 6.50-10 | 6.50-11 | 590 | 175 | 775 | 1950 | 1500 | 1875 | 1395 |
12 | LQ301 | 13 | 5.00F | 6.50-10 | 6.50-11 | 590 | 175 | 900 | 2145 | 1650 | 2065 | 1535 | |
14 | LQ301 | 13 | 5.00F | 6.50-10 | 6.50-11 | 590 | 175 | 1000 | 2340 | 1800 | 2250 | 1675 | |
7.00-12 | 12 | LQ301 | 14 | 5.00S | 7.00-12 | 7.00-13 | 675 | 190 | 860 | 2680 | 2060 | 2575 | 1915 |
14 | LQ301 | 14 | 5.00S | 7.00-12 | 7.00-13 | 685 | 207 | 900 | 2755 | 2120 | 2650 | 1970 | |
8.25-12 | 12 | LQ301 | 16 | 5.00S | 8.25-12 | 8.25-12 | 735 | 216 | 720 | 3060 | 2585 | 2840 | 2270 |
7.00-15 | 14 | LQ301 | 12 | 5.5 | 7.00/7.50/8.15-15 | 7.00/7.50/8.15-15 | 761 | 213 | 900 | 3350 | 2575 | 3220 | 2395 |
250-15 (250/75-15) |
18 | LQ301 | 12 | 7.5 | 250-15 | 8.15/250/300-15 | 750 | 270 | 950 | 4745 | 3650 | 4565 | 3395 |
20 | LQ301 | 12 | 7.5 | 250-15 | 8.15/250/300-15 | 750 | 270 | 1050 | 5200 | 4000 | 5000 | 3720 | |
28*9-15 (8.15-15) |
15 | 8.15/250/300-15 |
