Heat Flux Sensor
- Application: -
- Market Type:After Market
- Price: Inquiry For It?
Quick Details
- OE Experience:
No
Product Name:Heat Flux Sensor
Heat Flux Sensor
Application
-
Product Description:
1.Heat Flux Sensor - gSKIN-XO Descriprion:
Robust heat flux sensor to perform measures under harsh conditions.
2.Heat Flux Sensor - gSKIN-XO Features:
- Ultra-high resolution of thermal energies and temperature differences
- Robust sensor
- Model with connectors compatible with all gSKIN(R) DLOG Data Loggers
- Sensor with conductive heat flux calibration cohering to ISO 8301
3.Heat Flux Sensor - gSKIN-XO Applications:
In-situ building monitoring, U-Value determination, environmental monitoring e.g. soil
4.Heat Flux Sensor - gSKIN-XO Technical parameters:
| Product |
| gSKIN XO |
| Detector Type |
| Thermoelectric |
| Surface Material (Sensing Area) |
| Polyamide |
| Sensing Dimensions (mm) |
| 30.0 x 30.0 x 3.3 |
| Heat Flux Range Min / Max [kW/m²] |
| -15/ 15 |
| Noise Equivalent Heat Flux per area [W/m²] / absolute [W] |
| 0.073 / 65.7 (Experimentally evaluated values under optimal steady state conditions). |
| Heat Flux Resolution per area [W/m2] with gSKIN® DLOG / absolute [W] |
| 0.09 / 81.0 (Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219). |
| Response Time (0-95%) [s] |
| n/a |
| Min. /Avg. Sensitivity (S) [V/(W/m²)] |
| 10.0/20.0 (Only a reference point). |
| Max. Compressive Force when clamped [kgf] |
| >32 (not specified) |
| Electrical Resistance [Ohm] |
| <150 |
| Thermal Conductivity [W/(m*K)] |
| 0.4 |
| Absolut Thermal Resistance [K/W] |
| 2.8 |
| Linearity with Power [±%] |
| 1 |
| Operating Temperature Range Min/Max [°C] |
| -50 / 80 |
| Calibration Accuracy [±%] |
| 3 |
| Calibration Temperature Range Min/Max [°C] |
| -30 / 70 (Refers to the heat flux measurement).V |
| Temperature Dependence of S [%/°C] |
| 0.25 (The sensitivity increases/decreases as the temperature goes above/below 22.5°C. |
| Homogeneity [±%] |
| 1 (Position dependent signal change across sensing area). |
| Cable Length (c) [cm] |
| 100 |
