Heat Flux Sensor
- Application: -
- Market Type:After Market
- Price: Inquiry For It?
Quick Details
- OE Experience:
No
Product Name:Heat Flux Sensor
Heat Flux Sensor
Application
-
Product Description:
1.Heat Flux Sensor - gSKIN-XP Descriprion:
Our medium-sized heat flux sensor, with superior quality, accuracy, and responsiveness. Available both without and with connector.
2.Heat Flux Sensor - gSKIN-XP Features:
Ultra-high resolution of thermal energies and temperature differences.
Low invasiveness and thickness.
Models with connector compatible with all gSKIN®DLOG Data Loggers.
All sensors with conductive heat flux calibration cohering to ISO 8301.
3.Heat Flux Sensor - gSKIN-XP Applications:
R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties.
4.Heat Flux Sensor - gSKIN-XP Technical parameters:
| Product |
| gSKIN XP |
| Detector Type |
| Thermoelectric |
| Sensing Dimensions (mm) |
| 10.0 x 10.0 x 0.5 |
| Heat Flux Range Min / Max [kW/m²] |
| -150 / 150 |
| Noise Equivalent Heat Flux per area [W/m²] / absolute [W] |
| 0.073 / 7.3 (experimentally evaluated values under optimal steady state conditions). |
| Temperature Difference Resolution [K] |
| 30 |
| Surface Material (Sensing Area) |
| Aluminum |
| Response Time (0-95%) [s] |
| 0.7 (Refers to the heat flux measurement). |
| Min. /Avg. Sensitivity (S) [V/(W/m²)] |
| 10.0/20.0 (only a reference point) |
| Max. Compressive Force when clamped [kgf] |
| < 10 |
| Electrical Resistance [Ohm] |
| < 150 |
| Thermal Conductivity [W/(m*K)] |
| 1.2 |
| Linearity with Power [±%] |
| 1 |
| Operating Temperature Range Min/Max [°C] |
| -50 / 150 |
| Calibration Accuracy [±%] |
| 3 |
| Calibration Temperature Range Min/Max [°C] |
| -30 / 70 (Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5°C). |
| Flexprint Length (f) [cm] |
| 5 |
| Temperature Dependence of S [%/°C] |
| 0.25 (The sensitivity increases (decreases) as the temperature goes above (below) 22.5°C). |
| Homogeneity [±%] |
| 1 (Position dependent signal change across sensing area). |
| Heat Flux Resolution per area [W/m2] with gSKIN® DLOG / absolute [W]: |
| 0.09 / 9.0 (Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219). |
