Image for Self Contained Analog Ultrasonic Proximity Sensor

Self Contained Analog Ultrasonic Proximity Sensor

Application: \
Market Type:After Market
Price: Inquiry For It?

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

OE Experience:
No

Product Name:Self Contained Analog Ultrasonic Proximity Sensor

Self Contained Analog Ultrasonic Proximity Sensor

Application

\

Product Description:

RPS-150A Ultrasonic Proximity Sensor Features

Adjustable Zero & Span
Broad Sensing Beam
Range 2 to 40 or 5 to 80
LED Strength Indicator
Analog Current & Voltage Outputs
Selectable Inverted & Non-Inverted Outputs
Short Circuit & Reverse Polarity Protected
Limit Switch Style Housing

RPS-150A Ultrasonic Proximity Sensor Description
The RPS-150A analog ultrasonic sensor is mounted in a limit switch style housing and is completely self contained. It is powered by 20-30VDC, and is reverse polarity protected. It also has a wide beam angle which enables it to detect a target that is not at right angles. A flat target can tilt up to 35 degrees and still be detected. The RPS-150A has 2 short circuit protected analog outputs, 4-20mA and 0-10VDC. These outputs can easily be inverted and can be scaled over almost any range by means of adjusting the zero & span control. For set-up purposes an LED signal strength indicator is provided. The RPS-150A ultrasonic sensors can be used as level control devices for liquid level and bulk materials.

This LED is green when not detecting and fades to RED as a target moves into place, depending on how much reflected signal is coming back from the target. The frequency of operation is 38.5kHz. There are two ranges available in this model 2 to 40 or 5 to 80. It also features a quick disconnect (QD) receptacle. The housing is constructed of PBT plastic and has standard 30mm x 60mm limit switch mounting dimensions as well as side holes for mounting the sensor on its side.

RPS-150A Ultrasonic Proximity Sensor Specifications

Operational Range:	Adjustable 2 - 40" Adjustable 5 - 80"
Power Input:	20 - 30VDC Reverse Polarity Protected
Input Current:	50mADC
Ambient Temperature:	0 - 60ºC or 32 - 140ºF
Humidity:	0 - 95% Non-Condensing
Housing:	PBT Plastic, Limit Switch Style
Outputs:	Current Sourcing Analog Output 4 - 20mA Inverted & Non-Inverted Load 0 Ohms to 500 Ohms Analog Voltage Output 0 - 10V Inverted & Non-Inverted Load 500 Ohms to infinity Short Circuit Protected
Transducer Frequency:	38.5kHz
Response Time: 2 - 40" 5" - 80"	22ms 52ms
Weight:	9.5 ounces

PART NUMBER	RANGE	OUTPUT / DESCRIPTION
RPS-150A-40 RPS-150A-80	2 - 40" 5 - 80"	0 - 10VDC and 4 - 20mA Analog - Cable Sold Separately 0 - 10VDC and 4 - 20mA Analog - Cable Sold Separately
F32-5001183 F32-5001186		2 meter QD Cable, M12 4-Pin 22AWG 5 meter QD Cable, M12 4-Pin 22AWG
