Image for 20kg To 10t Compression Load Cell

20kg To 10t Compression Load Cell

Application: -
Market Type:After Market
Price: Inquiry For It?

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

OE Experience:
No

Product Name:20kg To 10t Compression Load Cell

20kg To 10t Compression Load Cell

Application

-

Product Description:

F1821
Compression Load Cell

F1821 Compression Load Cell Size and Capacity

F1821 Compression Load Cell Features & Applications
Stainless steel load cell.
Its capacities range from 20kg to 10t.
It comes complete with 3m of load cell cable.
The protection class is IP66.
Stainless steel construction. Fully welded seal with stainless steel cover for hostile environment applications.
There are four holes in the background of the load cell, this makes it easy to install.
Apply for mechanical assembling, stamping force test and control which precision requirements are undemanding.Like pressing machine, Bearing assembly machine.
Transient force measurement and control of dynamic stamping equipment.
Hopper scale and tank scale dynamic weight control.

F1821 Compression Load Cell Technical Parameters

Specifications	Technique
Rated output	1.5±10% mV / V
Zero balance	±3 % F.S.
Non-linearity	0.5 % F.S.
Hysteresis	0.5 % F.S.
Repeatability	0.1 % F.S.
Creep (30min)	0.1 % F.S.
Temp.effect on output	0.05 % F.S. / 10°C
Temp.effect on zero	0.05 % F.S. / 10°C
Input impedance	385±10
Output impedance	350±3
Insulation	5000M/100VDC
Recommended excitation	10 V
Maximum excitation	15 V
Compensated temp range	-10 ~ 60 ºC
Operation temp range	-20 ~ 80ºC
Safe overload	150% F.S.
Ultimate overload	200 % F.S.
Cable size	Ø4×3000 mm
Protection class	IP66
Cable color code	Input: Red(+) Black(-); Output: Green(+) White(-);
