Image for 5kg To 2t Compression Load Cell

5kg To 2t Compression Load Cell

Application: -
Market Type:After Market
Price: Inquiry For It?

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

OE Experience:
No

Product Name:5kg To 2t Compression Load Cell

5kg To 2t Compression Load Cell

Application

-

Product Description:

F1818
Compression Load Cell

F1818 Compression Load Cell Size and Capacity

F1818 Compression Load Cell Features & Applications
Miniature load cell, low profile.
Designed for low profile compression service.
Miniature type with strain gauge technology.
Compact size with low profile.
Its capacities range from 5Kg to 2t.
It comes complete with 3m of load cell cable.
Stainless steel construction.
Fully welded seal with stainless steel cover for hostile environment applications.
It is suitable for a wide range of applications including testing or weighing systems, and it can be put into the device, in order to monitor the force. Measure the force in the limited space.
Various applications such as consumer electronics assembly, automation industry.

F1818 Compression Load Cell Technical Parameters

Specifications	Technique
Rated output	1.5±10% mV / V
Zero balance	± 2 % F.S.
Non-linearity	0.5 % F.S.
Hysteresis	0.5 % F.S.
Repeatability	0.1 % F.S.
Temp.effect on output	0.36 % F.S. / 10°C
Temp.effect on zero	0.18 % F.S. / 10°C
Input impedance	350±10
Output impedance	350±5
Insulation	5000M/100VDC
Recommended excitation	5 V
Maximum excitation	10 V
Compensated temp range	-10 ~ 60 ºC
Operation temp range	-20 ~ 80ºC
Safe overload	150% F.S.
Ultimate overload	200 % F.S.
Cable size	Ø2×3000 mm
Protection class	IP64
Cable color code	Input: Red(+) Black(-); Output: Green(+) White(-);
