3SP_O3_5 P O3 Sensor DESCRIPTION
SPECs printed sensors offer the performance of the best quality electrochemical sensors at a fraction of the price. SPECs printed sensors are also ultra-thin, offering easy integration into wireless, portable, and networked solutions. These sensors are ideal for health, environmental, industrial and residential monitoring, because of their high performance, low cost and small size.
3SP_O3_5 P O3 Sensor BENEFITS
Small Size with Low Profile (20x20x3 mm)
Long Life (10 years expected life)
Fast Response (< 15 seconds)
Low Power Consumption
Individually Calibrated (NIST Traceable)
ROHS Compliant
Improved stability and ppb performance
3SP_O3_5 P O3 Sensor APPLICATIONS
Air Quality Monitoring
Industrial Safety
Air Purification Control
3SP_O3_5 P O3 Sensor SPECIFICATIONS
Measurement Range | 0 to 5 ppm |
Lower Detection Limit | < 20 ppb (instrumentation dependent) |
Resolution | < 20 ppb (instrumentation dependent) |
Response Time | < 15 seconds typical |
Sensitivity nA/ppm @ 5ppm | -60 +/- 10 nA/ppm |
Expected Operating Life | > 5 years (10 years @ 23+/-3C; 40+/-10% RH) |
Operating Temperature Range | -30 to 50 C (-20 to 40 C continuous) |
Operating Humidity Range - non-condensin | 0 to 100% RH (15 to 95% continuous) |
Power Consumption | 10 to 50 uW (circuit & ambient O3 dependent) |
Gas/Vapor | Concentration | Typical Response PPM O3 |
Methane | 500 ppm | < 0.05 |
Nitrogen Dioxide | 10 ppm | 5 |
Hydrogen Sulfide | 25 ppm | -12.5 |
Carbon Monoxide | 400 ppm | < 0.05 |
Ozone | 5 ppm | 5 |
Chlorine | 10 ppm | 10 |
n-Heptane | 500 ppm | -0.2 |
