Quick Details

• Place of Origin:

  Sichuan, China

• Delivery Time:

  0

• Delivery Port:

  Shanghai

• OE Experience:

  No

Product Name:HT-XX-22E/16B2, parking sensor

HT-XX-22E/16B2, parking sensor

Application

universal

Product Description:

I. Features of parking sensor HT-XX-22E/16B2:

1). High Sensitivity;

2). High Reliability;

3). Less Power Consumption;

4). Waterproof.

II. Certifications: ISo9001/TS16949/RoHS

III. Specifications:Nominal Frequency   ( kHz )                   40±1   Capacity                   (   pf  )               2000±15% Sound Pressure Level (  dB )                 100±5  Sensitivity                  (  dB )                 -73±5   Ring Time                  (  ms )                  ≤ 1.2   Resistance                (   Ω   )                  500Directivity                   (   °  )                110×70Max. Input Voltage      ( Vp-p )                  150Operating Temp. Range(  °C  )              -35±80  Storage Temp.             (   °C )              -40±85

Chengdu HuiTong West-electronic Co., Ltd (HTW) is a leading manufacturer of Ultrasonic Sensor for car parking system in China.

HTW's predecessor was one of the earliest enterprises who started to do research and produce piezoelectric ceramics for the war industry in ...[Read More]

Company Profile:

• Main Product:

  (We Sell): Ultrasonic sensor,parking sensor,probe,piezoelectric ceramics

• Business Type:

  Manufacturer

• Current Export Market:

  North America, Western Europe, Eastern Asia, Southeast Asia, Mid East
