Dual Plate Check Valve
Check Valve
Cast Iron Valve
Standard: BS5153, EN12334, API 609
Flange drilling is according to BS4504, DIN2501, and ANSI B16.1
Working pressure: 10bar/16bar/25bar
Testing pressure:
Shell: 15bar/24bar/37.5bar
Seal: 11bar/17.6bar/27.5bar
Material: Ductile iron GGG40/50 or Cast IronGG25
Disc: Ductile iron/Aluminum Bronze, Stainless steel
Stem: Stainless steel
Seat: EPDM/Viton
Coating: Internal and external with fusion bonded epoxy coating min250μm or Liquid Epoxy painting
