Quick Details

• Output Power:

  3kw

• Length:

  105cm

• Width:

  35cm

• Height:

  40cm

• Output voltage:

  380V

• Place of Origin:

  Made In China

• Samples:

  Charge

• Sample Price:

  860USD

• Delivery Time:

  10 DAYS

• Packing:

  PLYWOOD CASE

• Delivery Port:

  Shanghai

• Max. Production Capacity:

  1000SETS PER MONTH

• Export Ratio:

  81% - 90%

• OE Experience:

  No

Product Name:IR Corrosion Resistant Thermal Insulation Pump

IR Corrosion Resistant Thermal Insulation Pump

Application

kenshine-pump

Product Description:

OEM No/Model: IR50-32-160
IR corrosion resistant thermal insulation pump
IR corrosion resistant thermal insulation pump is a single stage single suction cantilever centrifugal pump. It is the derivative of IH chemical centrifugal pump and mainly used in chemical, chemical fiber, petroleum, food, pharmaceutical and other industries to transport solution medium with high freezing point (or high crystallization point temperature) and corrosive high temperature liquids.

Technical parameters
The design pressure of the pump at room temperature is 1.6mpa
Flow Q=3.4 ~ 460m3/h
Pumped medium temperature is not higher than 250
head H=3.6 ~ 132m
Note: Our factory can also produce thermal insulation pumps of other materials according to the needs of customers.

structure
IR thermal insulation pump is horizontal radial part rear door structure(do not remove the pipeline during maintenance).
Body is axial suction, radial discharge intermediate support.
The bearing is lubricated with thin oil and the bearing stand is fitted with an oil level gauge and a water-cooling device.
The insulated steam line of the pump is connected with the external insulated steam system through flange or screw mouth.
The pump and motor are connected with an extended detachable coupling
 Model description:
For example: IR50-32-200 (A)
IR- Corrosion resistant thermal insulation pump
50- Suction diameter (50mm)
32- Discharge outlet diameter (32mm)
Nominal diameter of impeller (200mm)
A- The outside diameter of the impeller is cut for the first time

Our company is one professional manufacturer in centrifugal pump,chemical industrial pump, electromagnetic pump,submersible pump,self priming pump,sewage pump,diaphragm pump,gear pump,diaphragm pump,transfer pump,booster pump,feed water pump,pumps etc. They are widely exported all over the world.[Read More]
