Image for HW Mixed Flow Volute Irrigation Pump

HW Mixed Flow Volute Irrigation Pump

Application: kenshine-pump
OEM No/Model: 100HW-7
Market Type:After Market
FOB Price: USD 890
Other Price Term: FOB,CIF,CNF
Payment Terms: T/T
Samples: Charge
Minimum Order: 1Set/Sets

Contact Supplier no sign-up required

Add to Favorites

Product Details

Company Profile

Quick Details

Output Power:
7.5kw
Length:
126cm
Width:
42cm
Height:
48cm
Output voltage:
380V
Place of Origin:
Made In China
Samples:
Charge
Sample Price:
890
Delivery Time:
7 DAYS
Packing:
PLYWOOD CASE
Delivery Port:
Shanghai
Max. Production Capacity:
600SETS PER MONTH
Export Ratio:
71% - 80%
OE Experience:
No

Product Name:HW Mixed Flow Volute Irrigation Pump

HW Mixed Flow Volute Irrigation Pump

Application

kenshine-pump

Product Description:

OEM No/Model: 100HW-7

Mixed flow volute pump

HW mixed flow pump is between centrifugal pump and axial flow pump. The pump has Small size, light weight, simple structure and it is easy to use and maintain. The conveyed medium is clean water or similar liquid. HW mixed flow pump is suitable for farmland drainage and industrial water supply and drainage.

HW type mixed flow pump is horizontal single suction volute mixed flow pump. The pump is suitable for conveying clean water or other liquids with physical and chemical properties similar to water. It is used in farmland drainage and irrigation, industrial and urban water supply and drainage.

HW volute mixed flow pump is mainly composed of pump cover, impeller, pump body, pump shaft, shaft sleeve and bearing body (diameter 350MM) or bearing frame (diameter 400mm) and other main parts.

performance

capacity: 180-3665m3/h

Head: 3.0-20.7 m

Supporting power: 3-250kW

Features:

1. simple structure, convenient usage, high efficiency, small size, light weight

2. Transmission mode: direct transmission and variable transmission. The commonly used driven engines are electric motors and diesel engines. Motor with shaft coupling and diesel engine with pulley.

3. Pump rotation: Viewed from pump inlet the impeller is generally for counterclockwise.

Model Description:

HW-300 7 s

300: pump inlet and outlet diameter (300mm)

HW: Volute mixed flow pump

7: Head (7M)

S: structural form (front and back door open structure)

Adopt standard HW-S pump, with GB/T13008 JB/T6667 standard design and manufacture.

MODEL	Q(m³/h)	Hm	Speed	Efficiency(%)	Shaft powerkw	Matched powerkw	NPSHm
MODEL	Q(m³/h)	Hm	Rpm	Efficiency(%)	Shaft powerkw	Matched powerkw	NPSHm
100HW-7	70	7.5	2950	78	1.87	2.2	4
150HW-7	144	6.9	1450	85	3.26	4	4.5
200HW-6	288	6.7	1450	86	6.26	7.5	4
200HW-11	270	11	1450	85	9.63	11	4
250HW-7	450	7	980	83	1034	15	5.5
300HW-8	792	8	980	84	20.5	22	4
350HW-8	1000	8	980	85.5	25.5	30	5
350HW-12	1000	12	980	85	37.6	55	5.5
400HW-8	1200	8	730	85	31.17	37	5.5
400HW-14	1200	12	1450	84.2	61.3	75	6
500HW-6	1980	6.2	580	87	38.4	55	6
500HW-10	2492	9.8	730	87	76.4	90	5.5
650HW-5	4032	7	590	85	97.5	110	6
650HW-7	3663	7.6	485	88	86.1	110	5.5
650HW-10	4000	14	590	88	173	185	6
800HW-10	5980	12.2	490	88	225	250	5.5
800HW-16	7200	17.7	590	88	394.6	450	5.5
