Quick Details

• Output Power:

  5.5kw

• Length:

  45cm

• Width:

  45cm

• Height:

  125cm

• Output voltage:

  380V

• Place of Origin:

  Made In China

• Samples:

  Charge

• Sample Price:

  850USD

• Delivery Time:

  7 DAYS

• Packing:

  PLYWOOD CASE

• Delivery Port:

  Shanghai

• Max. Production Capacity:

  1000SETS PER MONTH

• Export Ratio:

  71% - 80%

• OE Experience:

  No

Product Name:IHG Stainless Steel Inline Transfer Pump

IHG Stainless Steel Inline Transfer Pump

Application

kenshine-pump

Product Description:

OEM No/Model: IHG50-200
Vertical stainless steel pipeline centrifugal chemical transfer pump
Pump material and application
IHG type vertical stainless steel pipeline centrifugal pump is made of stainless steel (SUS304,SUS316,SUS316L etc.) The stainless-steel pump is used for conveying corrosive liquid without solid particles. The corrosive liquid is like water. IHG Vertical stainless steel centrifugal chemical transfer pump is widely used in petroleum, chemical industry, metallurgy, electric power, papermaking, food and pharmaceutical and synthetic fiber sectors. Liquid temperature is -20 to 120.

Features
Vertical structure with same inlet and outlet
Closed coupling between pump and motor, no vibration, low noise
Shaft sea: mechanical seal with high-quality
Convenient installation and maintenance, disassemble pump connection nut to open rotor parts
Pump can be used by series or parallel
Pump can be installed vertically or horizontally.

Performance range
Q: 2-2000m3/h
H: 2-125m
Caliber:20-500mm
Closed impeller, stainless steel pump material
Motor: Standard motor or explosion-proof motor


Model explanation:
IHG50-200
IHG: Vertical stainless-steel centrifugal pump
50: Pump inlet(50mm)
200: impeller nominal diameter(200mm)

Our company is one professional manufacturer in centrifugal pump,chemical industrial pump, electromagnetic pump,submersible pump,self priming pump,sewage pump,diaphragm pump,gear pump,diaphragm pump,transfer pump,booster pump,feed water pump,pumps etc. They are widely exported all over the world.[Read More]
