Measurement Items
Luminous Intensity
Elevation
Optic Axis Deviation
1/With new technology of CMOS machine vision camera and high-speed DSP(Digital Signal Processor), all parameters of high-beam and low-beam are tested accurately and automatically.
2/With strong software function and LCD display, inspection, calibration and adjustment can be completed quickly.
3/Light Image Alignment technology, external interference can be eliminated, accurate and fast follow-light aiming is ensured, high-beam / low-beam inspection takes only 40 seconds.
4/Only 25 seconds needed for testing 2 headlights synchronously, suitable for busy inspection stations.
5/ Adopting frequency conversion driving, horizontal movement is steady and reliable.
Item |
Parameters |
Measuring Rage |
Central Height of Headlight: 50cm ~ 130cm Luminous Intensity: 0 ~ 120,000cd Deviation of Optical Axis: Up 1 30 ~ Down32 (Up 25cm/10m ~ Down 50cm/10m) Left 3 ~ Right: 3 (Left 50cm/10m ~ Right 50cm/10m) |
Measurement Accuracy |
Light Intensity of High Beam: ± 12% Optic Axis Deviation of High Beam: ± 12 Optic Axis Deviation of Low Beam: ± 15 Central Elevation of Headlight: ± 1cm |
Inspection Distance |
1m |
Power Supply |
AC 220V ± 10% 50Hz ±1Hz |
