AWA5636-3 Sound Level Meter
} Latest Digital Signal Processing Technology } Wide Dynamic Range } High Precision } Modular Design - on Demand Selection } Wide Warm Design, Operating Temperature from -15 to 50 } Complies with IEC 61672 Class 2 } Widely use in Industrial Noise Surveys ; machinery, vehicles, ships and, etc } May also used in Ambient Noise |
Item |
Parameters |
Microphone |
AWA14421 |
Frequency Range |
A, C, Z |
Time Weighting |
F, S, I, Peak |
Frequency Range |
20Hz~12.5k Hz |
Meas. Upper Range |
>130db |
Self-generated Noise |
<25dBA |
Display |
128×64 |
Outputs |
AC, DC, RS232 |
A/D Bits |
32k Hz |
Integrating Function |
Yes |
Measure Parameters |
Lp,Lep1S |
RS232 Interface |
Yes, with software |
USB Interface |
Optional |
Overrun instructions |
Yes, Limits can be setted |
Working Temperature |
-20 ~ 50 |
