Paper Moisture Meter MC-7828PP
Applications:
This instrument uses contact measurement. The moisture of the measured objects is measured by measuring the electrical conductivity between two electrodes.
Features:
* With storage and statistical functions. Can store 240 groups of measurements.
* Two presentations, digital display and color coded LED indication.
* Use the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement. It can obtain automatically the temperature corrected moisture value.
* Use USB data output to connect with PC.
* Provide Bluetooth data output choice.
Details:
| Sensor Type | Contact Type | |
| Range | 0~80% | |
| Accuracy | ±(0.5%n+1) | |
| Resolution | 0.1 | |
| Display | LCD | |
| LED Indicator | Green LED Represents a Safe,Air-dry State | |
| Yellow LED Represents a Borderline State | ||
| Red LED Represents a Damp State | ||
| The Statistics Available | Last value / Mean value / Max. value / Min. value / Number of Readings | |
| Memory | 240 groups | |
| OperationConditions | Temperature | 0~50ºC |
| Humidity | <90%RH | |
| Power Supply | 4x1.5V AAA Size(UM-4)Battery | |
| Dimensions | Main Unit | 150x65x30mm |
| Sensor | 265x44x44mm | |
| Length of electrode | 77mm | |
| Cross section size of electrode | 14x1mm | |
| Gap between 2 electrodes | 4mm | |
| Weight(Not Including Batteries) | 280g | |
| Standard Accessories | Main Unit | |
| Sensor | ||
| Carrying Case (B04) | ||
| Manual | ||
| Optional Accessories | USB Data Cable with Software | |
| Bluetooth Data Adapter with Software | ||
For more details,please feel free to contact us. Thank you!
