Quick Details

• Output Power:

  25kw

• Length:

  2.8m

• Width:

  0.9m

• Height:

  2.6m

• Output voltage:

  380V

• Place of Origin:

  Shenyang,China

• Samples:

  Not Available

• Delivery Time:

  30 Working Days

• Delivery Port:

  Dalian

• Max. Production Capacity:

  50 Sets Per Year

• Export Ratio:

  61% - 70%

• OE Experience:

  No

Product Name:Combibloc Brick-Shape Carton Aseptic Juice Packaging Machines (BZ-2500)

Combibloc Brick-Shape Carton Aseptic Juice Packaging Machines (BZ-2500)

Application

BZ-2500

Product Description:

BZ-2500 type Combibloc Brick-shape Carton Aseptic Juice Packaging Machines consist of three separate machines: Carton forming machine and filling machine. The entire machine is made of 304 food-grade stainless steel. The surface is special processed to be beautiful and durable in use.


1. Suitable for filling:

Milk, yogurt, cream, beaten egg, soy milk, juice, tea drink, corn drink, pure water, sauce, wine, cleaning solution, chemical product, sugar, grain, cornmeal, other dry powder, etc.

2. Technical parameter:

1. Capacity: 250--1000ml (can be filled by one machine)
2. Output: 800-1200 cartons/hour
3. Packing material: Cardboard carton / aluminium foil carton
4. Filling Temperature: Cold filling: 2-50 degC/ hot filling 88-92 degC
5. Cap: With cap (Optional)
6. Overall power: 23KW (three phases of electricity)
7. Size: (L*W*H): Carton forming machine: 1.3m*0.9m*1.5m
Capping machine: 0.8m*0.6m*1.2m
Filling machine: 2.0m*0.9m*2.6m
8. Compressed air pressure: 1.0-1.4 Mpa, Flow rate: 0.8-1.0M3/min, without oil, water and dust
9. Cooling water: Flow volume: 20L/ min Temperature: Normal temperature
10. Net Weight: 1200kg (carton forming machine: 300kg, capping machine: 100kg, filling machine: 800kg)
11. Installation requirement: Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle.

4. Payment terms
 1)T/T : 30% as deposit , 70% balance before shipment
 2) L/C at sight

5. Delivery time
  1) For automatic filling machine 60 days
  2) For semi-automatic filling machine 45 days
  3) For manual filling machine 30 days

6. After Sale Services
Shenyang Beiya Beverage Machinery Co.,Ltd will supply 12 months guarantee for all the equipments, and if customer need, we will send our technicians to customers factory, install the machines and train customer's staff to operate the machine. we will supply all the spare parts with cost price if customer need.

Shenyang Beiya Beverage Machinery Company is the earliest to research and design gable top carton filling machine in domestic market. It is a high technology company combining production and R&D as an integrated construction. Through introducing foreign advanced technology and independent R&D, ...[Read More]

Company Profile:

• Main Product:

  Filling Machine, Packing Machine, Packaging Machine, Beverage Filling Machine, Gable Top Carton, Aseptic

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa, Oceania

• Total Annual Sales:

  USD 5,000,001 - 10,000,000

Factory Profile:

• Number of Employees:

  Less than 50 People
