Quick Details

• OE Experience:

  No

Product Name:Automobile Sensor And Actuator Teaching Board

Automobile Sensor And Actuator Teaching Board

Application

BMW

Product Description:

Product Automobile sensor and actuator teaching board of Introduction:

This product selects the new original car engine and other system sensors and executing equipment materials as the basis of production, simulation engine operation, demonstrating the working process of automotive sensors and actuators system;

The teaching board is fully functional, easy to operate, safe and reliable.

Structure composition:

Engine electronic control unit, alarm control unit, security keys, engine of all kinds of sensors, actuators, detection terminal, fault setting system, large capacity storage battery or 12 v switching power supply, large color print circuit schematic diagram, control panels, mobile platform, operation instruction and collaborative task training instruction, etc.

Features:

1. Complete engine sensor and actuator system schematic diagram are painted on the panel.  With detection terminals, sensors, actuators and other signal parameters such as voltage, resistance, frequency and so on can be detected through instrumentation.

2, control switch and button, can truly demonstrate the working process of the engine sensors and actuators.

3. Digital display table shows the signal voltage value of each sensor;  Leds display the status of working components.

4. The fault simulation system can simulate the actual operating conditions and set up a variety of common faults in real cars.

5, the bottom part of the experimental table, the table to keep 30cm wide space, convenient placement of testing instruments and instruments/experimental reports, the surface of the paint baking process, with self-locking casters.

6, equipped with diagnostic seat, can read the fault code and data flow, etc.;  Theft matching and other operations.
