Quick Details

• Type:

  Diesel Engine

• No. of Cylinders:

  4 Cylinder

• Power:

  294KW/2200RPM

• Displacement:

  6.48

• Torque:

  1600/1100-1600

• Place of Origin:

  Shanghai China (Mainland)

• Brand Name:

  STEYR

• Model Number:

  WD615

• Warranty:

  2 Years

• Place of Origin:

  Shanghai China (Mainland)

• Delivery Time:

  25 DAYS

• Packing:

  STEYR

• Delivery Port:

  SHANGHAI

• OE Experience:

  No

Product Name:SINO TRUCK CHNTC STEYR WD615.327 WD615.329 WD615.338 WD615.340 ENGINE FOR COACH AND BUS

SINO TRUCK CHNTC STEYR WD615.327 WD615.329 WD615.338 WD615.340 ENGINE FOR COACH AND BUS

Application

all

Product Description:

SINO TRUCK CHNTC STEYR  WD615.327 WD615.329 WD615.338 WD615.340 ENGINE FOR COACH AND BUS

Hangzhou Engine Co., Ltd, China National Heavy-Duty Truck Group Shanghai stone diesel engine co.,ltd. (Hereafter referred to as Hangzhou Engine Co., Ltd, CNHTC)is currently the wholly owned subsidiary to China National Heavy- Duty Truck Group.

Model: WD615.327

Application:For coach

series:WD615series

Type:vertical in-line water cooling four strokes direct injection

Intake Mode:Turbocharging Intercooling

No. of Cylinder× Bore× Stroke(mm):6×126×130

Total Displacement(L):9.762

Rated Power/ Speed (kW/r/min):198/2200

Peak Torque/Speed(N.m/r/min):1150/1100-1600

Torque Rise(%):33.8

Fuel Consumption at Rated Conditions(g/kW.h):188

Oil Consumption(%):≤0.2

Max. Rated Speed Without load:2420±50

Stable Idle Speed(r/min):600±50

Emission Index:EUROIII

Model: WD615.329

Application:For coach

series:WD615series

Type:vertical in-line water cooling four strokes direct injection

Intake Mode:Turbocharging Intercooling

No. of Cylinder× Bore× Stroke(mm):6×126×130

Total Displacement(L):9.762

Rated Power/ Speed (kW/r/min):213/2200

Peak Torque/Speed(N.m/r/min):1160/1100-1600

Torque Rise(%):25.5

Fuel Consumption at Rated Conditions(g/kW.h):188

Oil Consumption:≤0.2

Max. Rated Speed Without load(r/min):2420±50

Stable Idle Speed(r/min):600±50

Emission Index:EUROIII

Model: WD615.338

Application:For coach

series:WD615series

Type:vertical in-line water cooling four strokes direct injection

Intake Mode:Turbocharging Intercooling

No. of Cylinder× Bore× Stroke(mm):6×126×130

Total Displacement(L):9.762

Rated Power/ Speed (kW/r/min):276/2200

Peak Torque/Speed(N.m/r/min):1500/1100-1600

Torque Rise(%):25.2

Fuel Consumption at Rated Conditions(g/kW.h):188

Oil Consumption(%):≤0.2

Max. Rated Speed Without load(r/min/):2420±50

Stable Idle Speed(r/min/):600±50

Emission Index:EUROIII

Model: WD615.340

Application:For coach

series:WD615series

Type:vertical water cooling four strokes direct injection

Intake Mode:Turbocharging Intercooling

No. of Cylinder× Bore× Stroke(mm):6×126×130

Total Displacement(L):9.762

Rated Power/ Speed (kW/r/min):294/2200

Peak Torque/Speed(N.m/r/min):1600/1100-1600

Torque Rise(%):25.4

Fuel Consumption at Rated Conditions(g/kW.h):188

Oil Consumption(%):≤0.2

Max. Rated Speed Without load(r/min/):2420±50

Stable Idle Speed(r/min):600±50

Emission Index:EUROIII

SHANGHAI STONE DIESEL ENGINE CO.,LTD Based on the retained characteristics of the Steyr WD 615 such as separate cylinder head , frame structure , dry liner etc . , the WD615 Euro III diesel engines adopt the leading technology in engines and emission. such as the 4 values / cylinder EC common rail fuel injection etc . , the main features are as follow s: 1. Through application of the internationally most advanced design means and test method, the engine has achieved the Euro III and Euro IV emission standard. The engine power is 400 hp and the B10 Life of the engine is 12000 hours. The noise of the complete engine is under 97 db . The calibration of the engine was performed in conformity with the EURO III emission requirements. When only the 160 MPa common rail pressure is used and pilot injection, post-injection and late injection are implemented, the engine is fully capable to undergo adjustment and calibration , applying the same common rail fuel injection . When a necessary exhaust gas after treatment system is added to, the EURO IV emission requirements that will come in effect in the future can be met with . 2. Completely new design based on the profile of the Styer EURO II diesel engine, On the principle of retaining the assembly connection dimension of the complete vehicle and the configuration of the complete engine as far as possible. This greatly facilitates matching the truck plant and meanwhile ensures the engine good drivability, so that the customers can save a large amount of time and expense for upgrading their products . 3. 80% of the parts of the WD 615 EURO III and WD615 EURO II are interchangeable. This means a good technical succession and versatility and facilitates the production of the manufacturers of the complete vehicles and the engine maintenance and parts purchase of the end users greatly .
