Quick Details

• Main Raw Material:

  FR4

Product Name:Rigid-Flex Pcb Manufacture

Rigid-Flex Pcb Manufacture

Product Description:

OEM No/Model: YZX-PCB10

PCB Process Capability
· processing layers:1-28 layers
· Finished thickness (thinnest - the thickest): 0.008 "~ 0.24" (0.20mm ~ 6.0mm)
· Minimum aperture: 6mil (0.15mm)
· Minimum line width / spacing :3-4 mil (0.076-0.10mm)
· Maximum board size: Single & Double 22 "x 43" (550 x1100mm), Multi-layer 22 "x 25" (550mm x 640mm)
· Impedance Control: ± 10%
· Surface Treatment: OSP,  HASL, Electric Nickel / Gold, Chemical nickel / gold, lead-free HASL , Gold finger, immersion Silver, Immersion Tin.
· Base materials: FR4 ( ShengYi, KB, International), high TG (TG150, TG170), halogen-free board (Halogen-free), high frequency plate (Rogers, Teflon, Taconic), made PTFE (PTFE) ,, AL aluminum plate (Berquist, Al-made basis), copper (Cu Base), Iron (Fe Base), ceramic substrate (Ceramic Base)

FPC Process Capability
· processing layers:1-6 layers
· Finished thickness (thinnest): 3mil (0.08mm)
· Minimum aperture: 4mil (0.10mm)
· Minimum line width / spacing: 2 mil (0.05mm)
· Maximum board size: 10 "x 45" (250x 1200mm)
· Surface Treatment: OSP,  HASL, Electric Nickel / Gold, , Chemical nickel / gold, lead-free HASL, Immersion Gold
· Insulation resistance: ± 1011 (Normal Normal
· Thermal shock resistance: 260 °C 10 sec.
· Processing materials: polyimide (PI), polyester (PET), polyimide (PI) + FR4

The quick-turn service
24 hours for 2-Layer sample
48 hours for 4-Layer sample
72 hours for 6-Layer sample

Shenzhen Sunsoar Electronic Co.,LTD is a professional Printed fast Circuit Board manufacturer. Production bases located in Shenzhen Bao’an. After years of continued innovation and development, we have now set a PCB Business Unit and an FPC Board Business Unit ,and our production ability has up to ...[Read More]

Company Profile:

• Main Product:

  Pcb/ Fpcb/ Pcba/ Rigid Pcb/ Rigid-flex Pcb Board

• Business Type:

  Manufacturer

• Current Export Market:

  North America, South America, Western Europe, Eastern Europe, Eastern Asia, Southeast Asia, Mid East, Africa, Oceania

• Total Annual Sales:

  USD 100,000 - 500,000

Factory Profile:

• Number of Employees:

  101 - 200 People
