Quick Details

• Voltage:

  12v

• Type:

  Water temperature gauge

• Weight :

  5kg

• Material:

  other

• Place of Origin:

  China

• Samples:

  Not Available

• Delivery Time:

  In Stock

• Packing:

  New In Box

• Delivery Port:

  Shenzhen

• Max. Production Capacity:

  100PC/Month

• Export Ratio:

  71% - 80%

• OE Experience:

  No

Product Name:Rosemount 3051SFC Wireless Compact Orifice Plate Flow Meter

Rosemount 3051SFC Wireless Compact Orifice Plate Flow Meter

Application

rosemount

Product Description:

OEM No/Model: 3051SFC
Rosemount  3051SFC Wireless Compact Orifice Plate Flow Meter
The Rosemount 3051SFC Wireless Compact Orifice Plate Flow Meter is a versatile multivariable measurement solution that delivers best-in-class accuracy without the cost of wiring via a secure WirelessHART? network. This flow meter offers simple installation between any existing raised-face flanges. In addition, this device is built with a compact orifice plate that provides flow measurements for closed loop control, general purpose monitoring and custody transfer applications.




Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.
Specifications

DOWNLOAD FULL SPECS
Measurement Type   Differential Pressure and Static Pressure
                   Differential Pressure
Accuracy           0.40 Beta: ±1.30% of flow rate
                   0.50 & 0.65 Beta: ±1.30% of flow rate
Stability          Up to ±0.15% of Upper Range Limit (URL) for 15 years
Warranty           Up to 15-year limited warranty
Rangedown          Up to 200:1 (14:1 flow turndown)
Measurement Range  Up to 2000 psi (137,89 bar) differential, Up to 3626 psia (250,00 bar) absolute, Up to 3626 psig (250,00 bar) gage
Line Size          0.5 to 12 in. (15 to 300 mm)
Output             Differential pressure, static pressure, scaled variable
                   Communication Protocol WirelessHART?
Process Wetted Material   316 SST
Diagnostics               Basic Diagnostics
Certifications/Approvals   NACE, hazardous location, see full specs for complete list of certifications
Update Rate                1 sec. to 60 min., user selectable
Power Module Life          Up to 10-year life, field replaceable (order separately)
Wireless Range             Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km)


Features

WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy
General purpose plate design delivers reliable and accurate flow measurement for gas, liquid and steam service
Orifice plate available in 0.5 - 12 in. (15 - 300 mm) line sizes for application flexibility
All-welded, resilient SuperModule? sensor offers best-in-class accuracy in harsh environments and applications
Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation
Flowmeter technology eliminates unnecessary pipe penetrations for an integrated, trouble-free solution
Primary element includes optional self-centering mechanism for simplified installation
SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
Easy installation enables quick instrumentation of measurement points without the cost of wiring
