OEM No/Model: 3051CFC
Rosemount 3051CFC Wireless Compact Conditioning Orifice Plate Flow Meter
The Rosemount 3051CFC Wireless Compact Conditioning Orifice Plate Flow Meter is an industry-leading flow measurement solution featuring >99% data reliability delivered via a secure WirelessHART? network. This device includes a compact orifice plate with a patented, 4-hole design that offers accurate measurement in turbulent flow conditions. This conditioning orifice plate reduces pipe straight run, requiring only two pipe diameters (2D) upstream and downstream.
Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.
Specifications
DOWNLOAD FULL SPECS
Measurement Type Differential Pressure
Accuracy Up to ±1.95% of flow rate
Stability Up to ±0.20% of Upper Range Limit (URL) for 10 years
Warranty Up to 5-year limited warranty
Rangedown Up to 150:1 (8:1 flow turndown)
Measurement Range Up to 1000 inH2O (2,48 bar) differential
Line Size 2 to 12 in. (50 to 300 mm)
Output Differential pressure, scaled variable
Communication Protocol WirelessHART?
Process Wetted Material 316 SST
Diagnostics Basic Diagnostics
Certifications/Approvals NACE?, hazardous location, see full specs for complete list of certifications
Update Rate 2 sec. to 60 min., user selectable
Power Module Life Up to 10-year life, field replaceable (order separately)
Wireless Range Internal antenna (225 m)
Features
WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
10-year stability and 8:1 flow turndown (150:1 rangedown) produce reliable measurements and application flexibility
Patented 4-hole orifice plate design enables accurate flow measurement near upstream flow disturbances.
Complete flow assemblies are leak-tested and calibrated to reduce leak points up to 70% and simplify installation
Innovative orifice plate requires only 2D upstream and downstream to reduce pipe straight-run requirements SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
Easy installation enables quick instrumentation of measurement points without the cost of wiring
