The 2SB1228-USK is one member of the 2SB1228 family that is designed as one kind of silicon PNP epitaxial planar silicon darlington transistor that has four points of features:(1)adoption of FBET, MBIT processes;(2)large current capacity;(3)low collector-to-emitter saturation voltage;(4)micaless package facilitating mounting. And this device can be used in control of motor drivers, printer hammer drivers, relay drivers, and constant voltage regulators.
The absolute maximum ratings of the 2SB1228-USK can be summarized as:(1)collector-base voltage: -110 V;(2)collector-emitter voltage: -100 V;(3)emitter-base voltage: -6 V;(4)collector current: -8 A;(5)collector power dissipation: 2.0 W;(6)junction temperature: 150 ;(7)storage tmeperature range: -55 to +150 .
