Product Attribute:
Color:Black
Production Description:
Breif Specification:
1) Main Functions: Real-time map tracking, Speed Recording, G-force activity
2) Memory:Support TF card,Up to 32GB
3) Video : AVI format,1280*720,720*480
4) Photo : JPEG, 2560*1920
5) Battery type : Lithium-ion, 1800 MA
6) Battery recording time : about 2 hours
7) USB: 2.0 (Hs)
8) Operation systems:Windows ME/ 2000/ XP/ Vista or above
Single lens wide angle camera forward facing Automatic video incident capture;
Recording with H.264 codec;‘Red Button’ trigger enables manual video capture;
Enough events memory more than 30 recordings;Eco Driving indicator for your energy saving drive;
VGA 640*480 pixel viewing screen very low light, 1 Lux;Provide Event review manager ‘WSH manager’
How to analyze incident video recording?
Event recordings are downloaded into the PC via a Memory Stick, or USB cable;Event recordings can be analyzed in WSH manager on the PC;
WSH manager provides strong video management tool, such as playback speed control, frame level move etc.
G-sensing data displayed on the graph in detail;Any single frame of video can be easily captured or printed on this software;
Recorded events can be converted to AVI format for distribution via email;Preview function allowing easy file search;
WSH manager allow you to control the device in Setup menu, providing sensitivity option, video resolution option and Video frame option.
How it works?
What is WSH Car Black Box?
WSH camera is installed on the front mirror of vehicle facing forward >>>
Events occur, such as sharp breaking, rapid acceleration, excessive cornering or sudden impact or shocks…
Multi-axis accelerometer (G-sensor) trigger events…
20seconds Before Accident 20seconds After Accident .40 seconds video clip is store internal memory
The WSH Car Black Box is an innovative event recording system, capturing comprehensive vehicle data from triggered events. The WSH car black box is triggered by an advanced process including a multi-axis accelerometer that measures sudden movements such as swerving, sudden braking and shocks. Captured data includes 20 seconds of video footage before the triggered event and 20 seconds after the trigger.
This incident recording is downloaded into the PC via a Memory Stick, or USB cable, allowing it to be analyzed in detail.
