12 X 2 Trailer Hydraulic Uni-Servo Brake Assembly - Dacromet / Galvanized Coated

12 X 2 Trailer Hydraulic Uni-Servo Brake Assembly - Dacromet / Galvanized Coated

Application:  custom trailers and boat ...

Market Type:  After Market

Packing:  Standard Seaworthy Packing

Samples:  Not Available

Place of origin:  China

Export Ratio:  91% - 100%

Price Terms:  FCA

Minimum Order:  300Piece/Pieces

Product Attribute:

Applicationt:

custom trailers and boat trailers

Production Description:

  Hydraulic Drum Brake Assembly   12 x 2 inch Drum
  Trailer Hydraulic Brakes   5200 lb, 6000 lb, 7000 lb
  Hydraulic Backing Plate   Uni-Servo
  12" Trailer Brake Assembly   Manual Adjustment

The 12 inch trailer hydraulic brakes fit 14 1/2 to 16 ½ wheels. The mounting flange is 5-bolt pattern. This 12 inch trailer brake has marine -grade (galvanized or dacromet coated) steel, it offerssuperior corrosion resistance. Trailer hydraulic uni-servo brake wholesaler recommend these to customers who want to replace the boat trailer brakes of 5.2k lbs, 6k lbs or 7k lbs axle.
Features

  • Designed for use with surge-type trailer brake actuators.
  • Dacromet / Galvanized coated offers the best value of protection for salt water applications.
  • Uni-Servo brakes have 15 - 20 percent braking in reverse.
  • Periodic manual adjustment required.
  • This brakes exchange with most quality hydraulic brakes, such as Dexter, Demco, Hayes, etrailer, LCL etc.
Specifications

  • Dimension: 12 inch x 2 inch
  • Axle Capability: 5200 lbs, 6000 lbs, 7000 lbs Axle (14.5", 15", 16" and 16.5"Wheel)
  • Mounting Flange Bolt Pattern: 5 bolt
  • Brake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side / RH
Product Composition

  • 12 x 2" Riveted Uni-Servo Brake Shoe Kit x 1
  • Dacromet / Galvanized Back Plate x 1
  • Single-Servo Aluminum Wheel Cylinder x 1
  • Stainless Steel Springs x 2
