Product Attribute:
Tensile stength:900Mpa
Standard:DIN
color:blue gold black green etc
head:taper cap button flange torx 12 point etc.
technical:hot forged head rolled threads
Applicationt:
audi, BMW, Ford, Lexus, Mazda
Production Description:
High quality hot forged titanium screw GR5
Material: Ti Grade 2, Grade 5(Ti6Al4V), Grade 7, Ti6Al4V ELI
Standard: DIN 912/931/933/7991/1662/1665/6912/65438 etc.
Size: M3~22XCustom length
Colour: Gold, Blue, Purple, Green, Ti natual
Strength class: 8.8/10.9/12.9
Application: Racing industry like racing motorcycles and cars,racing bicycles,sailing boat and medical industry etc
Products category
avaliable colour : blue, green, purple, gold, black, rainbow
avaliable head:taper, hex, flange, button, torx, cap, 12point head etc.
Bright spot:
1. aerospace grade material--titanium Gr5
2. The head of our bolt are Hot forged for higher strength,instead of Machined head.
3.The threads of our bolt are Rolled for greater fatigue resistnace and avoidiing galling,instead of Cut threads.
Quality Guarantee:
"Quality begins with design and carries through final inspection and field testing"
--Raw material(Ti bars):
Aircraft grade Titanium alloy 6Al4V and Ultrasonic inspection for Ti6Al4V bars
--Advanced processing method:
Forged Head improves superior strength,Rolled Threads to produce greater fatigue resistance and rdeuce galling
--Quality inspection conducted by QC before delivery
Sampling inspection for Chemical composition and Michanical properties like Tensile strength etc
Dimension measurements like Thread size,Height of head,Depth of socket etc
--MTC
Related Certs for Chemical composition and Mechanical properties will be offered along with goods delivery
--Returns of defected products
If the products fail to meet the agreed requirements when clients recieve the goods,they will be replaced, subject to availability, or refunded at clients discretion.
