Product Attribute:
Output Power:210/220w
Length:500mm
Width:580mm
Height:610mm
Output voltage:210V
Output current:220A
Applicationt:
audi, Beiqi, chevolet, Ferrari, fiat
Production Description:
Application:
TH-2004D dispensing robot offer reliable operation with excellent repeatability for precise application of adhesives, sealants and lubricants in many assembly and manufacturing processes.
Dedicated to glass glue, high-viscosity glue sealant, polyurethane, silicone and other packaging.
Features:
1.Have rapid emptying and transient back to the lock function, the glue can easily be turned off no residue.
2.As different material be packed require select different feed system ,eg.hard pack, soft pack, bottled.
3.Professional dispensingsoftware combination of feed system and arm runing control to achieve the synchronization control.
4.Triaxial dual rail robotic arm, the Z-axis brake motors, greatly increased the stability of the equipment and motion accuracy.
5.PLC Controller, Easy to program - Dedicated dispensing software eliminates the need for complex robot language programming.
6.Increase the parameters display with programmer , more intuitive operation.
7. Each axis with 2 linear guide rail, More stable
8. As customer production require add the I / O interface, easy add other device for the equipment
9.XY work range increased 20MM
10.Single machine can operation.
Specifications:
|
ITEM
|
TH-2004D-300KG
|
TH-2004D-400KG
|
TH-2004D-500KG
|
|
X/Y/Zworking range
|
300 x 300 x 100mm
|
400 x 400 x 100mm
|
500 x 500 x 100mm
|
|
Standard |
CE Approved
|
|
XY/ZMaximum Load |
15 kg / 6 kg
|
|
XY/Z Speed |
0.1-800/350 mm/Axis
|
|
Repeatability |
±0.01mm/Axis
|
|
Data memory capacity |
9999programs
|
|
Display way |
LCD display
|
|
Drive System |
Precision micro-stepper motor
|
|
Transmission |
Timing Belt/ Precision Linear Guides
|
|
Edit Programming |
Handheld Programmer
|
|
I/O Signals |
4 Inputs / 4 Outputs
|
|
Patterns |
Dots,Line,Potting,
Filling,,Encapsulation,Sealing,Coating,Jetting
|
|
Power Supply |
AC110V/220V Internal conversion
|
|
Working Temperature |
0 40 °C
|
|
Relative Humidity |
2090%(no condensation)
|
|
Dimensions (WxDxH) mm
|
500 x 580 x 610mm
|
600 x 680 x 610mm
|
700 x 780 x 610mm
|
|
Weight
|
34kgs
|
39kgs
|
46kgs
|
