Voltage:12v
Current:10A
Color:White
Material:ABS Alloy
Feature:Mechanical
Wiring:Null Line and Live Line
Acura
cars thermal switch used: motorcycle tank thermostat range for passenger cars application , trucks, tank car, cooling fan motor, favor of an automobile engine to maintain optimal temperature. cars thermal switch conditions relative humidity at + 20 Environment issued 95% atmospheric pressure 86-106Kpa working position: Any cars thermal switch technology parameters Operating Temperature: 0 --150 (any temperature) reset temperature: 6 --40 (temperature difference with the action) Rated voltage: DC24V-250V Current Rating: 10A Insulation resistance: DC500V 10M (normal) Contact resistance: resistance Rs50m (initial value) when the static and dynamic contact exposure Open resistance: static and dynamic contact resistance Rk10M off withstand voltage: AC1000V 50HZ 30S (normal) switch life: its own on-off switching times 100,000 times (normal) Common thread: M12 * 1.5; M14 * 1.5; M16 * 1.5; M20 * 1.5; M22 * 1.5, G2 / 1 Note: The temperature may need to develop a series based on other customers, different interfaces and loading plug form, different electrical parameters of products
