28kVA ISUZU Silent Diesel Generator

28k VA ISUZU Silent Diesel Generator Technical Datasheets

Genset model

TG28JIS

Genset Type

Silent Enclosed

Rate Voltage

440V//415V/400V/380V/230V/220V/110V

Frequency

50Hz

Speed

1500rpm

P.F(COS)

P.F. 0.8

Prime Output Current

34.8A

Prime Power

20kW / 25kVA

Standby Power

22kW / 28kVA

Engine

Brand

ISUZU

Model

JE493DB-02

Alternator

Brand

Stamford

Model

SOL2-P1

Controller

Brand

DEIF

Model

SGC-420

Genset Weight

660kgs

Genset Dimensions

L2080 * W 880 * 1100

ISUZU Diesel Engine Data

Brand

Isuzu

Engine Model

JE493DB-02

Number of Cylinders

4 Cylinder in Line

Cycle

4-troke

Aspiration

Natural Intake

Displacement

2.771L

Compression ratio

18.2L

Bore×Stroke

93*102mm

Speed

1500rpm

Prime Power

24kW

Standby Power

27kW

Speed Governor

MECH or Electrical

Cooling System

Forced water cooling cycle

Starting system

DC Motor

Fuel Consumption at 100% Load

207g/kwh@1500rpm

Stamford Alternator Data

Brand

Stamford

Model
