4JB1 ENGINE

Product Attribute:

Model : 1

Supply Ability:10000 Unit/Units per Month

Delivery Details:30 days

Production Description:

ISUZU 4JB1 ENGINE

Nature Intake Air Engine Parameter

1,Specification:

Air induction:Nature intake air
Operation Layout: 4-Cycle Water Cooled, Direct Injection System
Number of Cylinders-Bore*Stroke:4-93mm×102mm
Size (L*W*H):734×612×682
Net Weight:224KG
Displacement:2.771cc
Compression Ratio:18.2
Fuel Supply:Direct Injection
Lubrication:Forced Feed type
Cooling type:Liquid Cooling
Starting type: Engaged Magnet Type
Stopping type:Fuel Cut-off By Stop Motor

2. Performance:

Rated Output Power:57kw/3600 RPM
Max Torque:172N.m/2000Rpm
Idle Speed:750RPM
Max Racing: 4200RPM
Fuel Consumption:224g/kwh
Cold Starting: -25°C
Temp of Exhaust Gas:<600°C
Noise:Max 106dB With JIS a Characteristics
