Product Attribute:
Model : 1
Supply Ability:1000 Unit/Units per Month
Delivery Details:30 DAYS
Production Description:
cummins engine ISDe285-30 for Coach
SHANGHAI STONE DIESEL ENGNE CO.,LTD
cummins engine ISDe285-30 for Coach
power: 210KW/2500RPM
Emission EURO III
Type: turbocharger and intercooler
Engine Model: ISDe285-30
Engine Type: 6 Cylinders in Line
Displacement: 6.7 L
Rated Speed: 2500 rpm
Rated Power: 210 kW(285 HP)
Max. Torque/Speed: 970 N.m @1400 rpm
Aspiration Method: T-charged & Intercooled
Emission Standard: Euro III
Fuel Consumption: 251 g/kw.h
Packing Size(L*W*H): 1300*800*950
Gross Weight: 550 Kg
Delivery Time: 7-15 working days
Payment Terms: T/T ,L/C
Cummins ISDe270-30 Diesel Engine for Vehicle
General Information of Cummins ISDe285-30 Diesel Engine for Vehicle
Engine Model ISDe270-30
Engine Type 6 Cylinders, in Line
Displacement 6.7 L
Bore*Stroke(mm) 107 * 124
Compression Ratio 17.3 : 1
CPL Number -
Net Weight (with flywleel & alternator) 530 Kg
Overall Diemension(L*W*H) 1060mm*700mm*860mm
Technical Specification of Cummins ISDe285-30 Diesel Engine for Vehicle
Certification Euro III
Aspiration Turbocharged & Inter-cooled
Fuel System Bosch Pump
Electrical System(Starter Motor/Alternator) 12V/500A; 24V/250A
Lowest Starting Temp.(with/without auxiliary system) -10°C/-25°C
Engine Cooling Fluid Volume 9.4 L
Performance Data of Cummins ISDe285-30 Diesel Engine for Vehicle
Rated Power/Speed 210kW/285HP @ 2500rpm
Max.Torque/Speed 970N.m @ 1400rpm
Fuel Consumption @ Rated Power 50.4 l/hr
Idel Speed 600~800 rpm
Max. Continuous Running Altitude 2000 m
ISDe140 30 103/2500 450/1400 Coach
ISDe160 30 118/2500 600/1400 Coach
ISDe180 30 136/2500 650/1400 Coach
ISDe140 31 103/2500 550/1400 bus
ISDe160 31 118/2500 600/1400 bus
ISDe185 31 136/2500 650/1400 bus
ISDe185 30 136/2500 700/1400 Coach
ISDe210 30 155/2500 750/1400 Coach
ISDe230 30 169/2500 900/1400 Coach
ISDe245 30 180/2500 925/1400 Coach
ISDe270 30 198/2500 970/1400 Coach
ISDe285 30 210/2500 970/1400 Coach
ISDe185 31 136/2500 700/1400 bus
ISDe210 31 155/2500 800/1400 bus
ISDe230 31 169/2500 900/1400 bus
ISDe245 31 180/2500 925/1400 bus
ISDe270 31 198/2500 970/1400 bus
ISDe140 40 103/2500 550/1400 Coach
ISDe160 40 118/2500 600/1400 Coach
ISDe180 40 132/2500 700/1400 Coach
ISDe200 40 140/2500 740/1400 Coach
ISDe140 41 103/2300 550/1400 bus
ISDe160 41 118/2300 600/1400 bus
ISDe185 41 136/2300 700/1400 bus
ISDe185 40 136/2500 700/1400 Coach
ISDe210 40 155/2500 800/1400 Coach
ISDe230 40 169/2500 900/1400 Coach
ISDe245 40 180/2500 950/1400 Coach
ISDe270 40 198/2500 970/1400 Coach
ISDe285 40 210/2500 1020/1400 Coach
ISDe300 40 221/2500 1100/1400 Coach
ISDe198 41 146/2500 900/1400 bus
ISDe210 41 155/2300 800/1400 bus
ISDe230 41 169/2300 900/1400 bus
ISDe245 41 180/2300 950/1400 bus
ISDe270 41 198/2300 970/1400 bus
ISLe270 30 201/2100 1050/1000-1700 Coach
ISLe290 31 213/2100 1050/1000-1900 bus
ISLe310 31 228/2200 1200/1000-1700 bus
ISLe325 31 239/2200 1350/1100-1600 bus
ISLe290 40 213/2100 1050/1100-1700 Coach
ISLe310 40 228/2100 1200/1100-1700 Coach
ISLe315 40 231/2100 1200/1400 Coach
ISLe325 40 239/2100 1350/1100-1500 Coach
ISLe340 40 250/2100 1425/1100-1500 Coach
ISLe360 40 265/2100 1550/1100-1400 Coach
ISLe375 40 275/2100 1550/1400 Coach
ISLe400 40 294/2100 1700/1400 Coach
ISLe290 41 213/2100 1050/1100-1700 bus
ISLe310 41 228/2100 1200/1100-1700 bus
ISLe325 41 239/2100 1350/1100-1500 bus
ISLe340 41 250/2100 1425/1100-1500 bus
