Product Attribute:
Type:Diesel Engine
No. of Cylinders:4 Cylinder
Power:96KW to 101.5KW
Displacement:3.153
Torque:313
Place of Origin:Shanghai China (Mainland)
Brand Name:NISSAN
Model Number:QD32Ti
Production Description:
Nissan QD32Ti diesel engine
Type Supercharged inter-cool
No. of cylinder-bore×stroke 4—99.2×102
Displacement 3.153
Type of combustion chamber Swirl combustion chamber
Compression ratio 22:1
Rated power/speed (KW/r/min) 101.5/3600,96/3600
Max torque/speed(N·m/r/min) 313/2000, 280/2000
Full load min.fuel onsumption 225
Max. idling speed 4600-4800
Idling steady speed 700±50, 850±50 (when air condition is open.)
Oil & fuel consumption percent ratio % ≤0.3
Firing order 1-3-4-2
Emission standard EuroII
Net weight 275
Overall dimension(L×W×H)mm 721×701×665
Application The series diesel engine mainly applied all kinds of light duty trucks, cross-country vehicle, pick-up, light duty bus, MPV and ect.
|
Model
|
Nissan QD32Ti diesel engine
|
|
Type
|
Supercharged inter-cool
|
|
No. of cylinder-bore×stroke
|
4—99.2×102
|
|
Displacement
|
3.153
|
|
Type of combustion chamber
|
Swirl combustion chamber
|
|
Compression ratio
|
22:01
|
|
Rated power/speed (KW/r/min)
|
101.5/3600,96/3600
|
|
Max torque/speed(N·m/r/min)
|
313/2000, 2800/2000
|
|
Full load min.fuel consumption
|
225
|
|
Max. idling speed
|
4600-4800
|
|
Idling steady speed
|
700±50, 850±50 (when air condition is open.)
|
|
Oil & fuel consumption percent ratio %
|
≤0.3
|
|
Firing order
|
1-3-4-2
|
|
Emission standard
|
Euro II
|
|
Net weight
|
275
|
|
Overall dimension(L×W×H)mm
|
721×701×665
|
|
Application
|
The series diesel engine mainly applied all kinds of light duty trucks, cross-country vehicle, pick-up, light duty bus, MPV and etc.
|
