Product Attribute:
Type:Diesel Engine
No. of Cylinders:6 Cylinder
Power:108kw to 179kw
Displacement:8.3
Torque:674 to1028 N.m
Place of Origin:Shanghai China (Mainland)
Brand Name:cummins engine
Model Number:6CTA8.3 C260
Production Description:
SHANGHAI STONE DIESEL ENGINE CO.,LTD CAN SUPPLY CUMMINS ENGINE 6CTA8.3 C260 for construction machine
CUMMINS ENGINE 6CTA8.3 C260 260HP/2200RPM 194KW/2200RPM cummins diesel engine.
cummins engine 6CTA8.3-C260
Rated Power 194kW/2200r/min
Peak Torque 1135N.m/1500r/min
Displacement 8.3L
Bore 114mm
Stroke 135mm
Cylinders 6
Technical Specification
Aspiration "Turbocharged
& Aftercooled"
Pump Type PB
Governor RSV
Weight Dry 637kg
Instant inertia of rotational part (Without flywheel) 0.37kg.m2
Center Of gravity Distance From Front End Of Cylinder Body 427mm
Center Of Gravity Distance Above Crank Centre Line 163mm
Cummins Engine 4BT3.9 6BT5.9 6CT8.3 6LT8.9 M11 NT/A KT/A
1.Cummins genuine engine
2.Made in DCEC CCEC (made in china)
3.Used for trucks,buses,construction machines,marine ship
| Item | Model | Power/Speed(kw/rpm) | Remark |
| 1 | 4BT3.9-C80 | 60/2000 | Industrial Use |
| 2 | 4BT3.9-C100 | 75/2400 |
| 3 | 4BT3.9-C105 | 77/2800 |
| 4 | 4BTA3.9-C125 | 93/2200 |
| 5 | 4BTA3.9-C130 | 97/2500 |
| 6 | 4BTAA3.9-C115 | 95/2500 |
| 7 | 4BTAA3.9-C125 | 93/2200 |
| 8 | 6BT5.9-C150 | 112/2400 |
| 9 | 6BTA5.9-C150 | 112/1800 |
| 10 | 6BTA5.9-C170 | 125/2300 |
| 11 | 6BTA5.9-C180 | 132/2200 |
| 12 | 6BTAA5.9-C180 | 132/2200 |
| 13 | 6CTA8.3-C215 | 160/2200 |
| 14 | 6CTAA8.3-C215 | 160/2200 |
| 15 | 6CTA8.3-C240 | 179/2200 |
| 16 | 6CTA8.3-C260 | 194/2200 |
| 17 | 6LTAA8.9-C325 | 239/2200 |
We can provide Cummins engines used for Industry, Bus, Marine, Generator Set and water pump. More details, please contact us. Thanks.
