Product Attribute:
Place of Origin:Guangdong China (Mainland)
Brand Name:OEM
Model Number:LC-43DVR1080P(car dvr mirror)
Type:Interior Mirror
Function:reverse camera/auto-dimming
size:4.3inch
Video input:NTSC/PAL
External memory:supporting SDHC card up to 32GB
Certification :CE/FCC/E-MARK
Operating temperature: -20 to + 80 degrees
lens: 140°wide-angle lens
DVR camera: can be rotated front and back
Language:English/Chinese/Korean/Japanese/Russian
warranty:24months
material : ABS+PC
Production Description:
Key Feature:
1. Automatic activation when selecting reverse
2. Auto adjusting brightness of 3.5" monitor display
3. High resolution(Digital)3.5 inch LCD monitor
4. High brightness 1200cd/ squre meter
5. Original equipment look & quality
6. Glare surpressing mirror
7. Installs using original windscreen mount
8. Wire casing for neat looking and easy fitting
9. Two Video Inputs: AV1 to VCD/DVD/TV/GPS and etc (defaulted) AV2 to backup camera
11. Mirror view and normal view switchable
12. Adopt digital high-resolution imaging process: 480 TV lines
13. Extra-low illumination of 0.3 Lux for clear night vision
14. Automatic white balance function
15. Viewing angle: 170°
16. Water-proof, shock-proof and anti-jamming functions
17. Mini size: diameter:18.5mm, length:22mm
18. Pin nailed installation, hiding mounting at upper side of license-plate
19. Automatically switch on when reverse gear is engaged.
20. 4 sensors detect obstacles behind vehicle and display distance data in the monitor
21. Audible alert emits when sensors detect obstacles within effective range.
22. Dust-proof control box with switches for adjusting camera frequency
23. Detachable sensor with water-proof joiner, easy for replacing sensor.
Specification of Camera:
Image device: 1/4-inch colour vc0702
TV system: NTSC
Resolution: 480 TV lines
Electric Shutter: NTSC :720Lines.25Field/sec
Effective pixels: NTSC: 720X 480
Minimum illumination: 0.3Lux
Viewing angle: 170 degrees (diagonal)
S/N ratio: >48dB (AGC-OFF)
Video output: RCA connector, 1.0vp-p, 75ohm
Current consumption: ≤120mA
Power supply: DC8V-12V
Operating temperature: -30 to 65 degrees centigrade, RH95% Max.
Storage temperature: -35 to 70 degrees centigrade, RH95% Max.
Other items: automatic white balance, AGC and BLC
Water-proof: Yes, to IP68 standard
