3205-BD-2HRS-TVH FAG Ball Bearings

Product Attribute:

Inner diameter:25mm

Bore Size:20mm

Outer Diameter:52mm

Type:Ball Bearing

Applicationt:

Daihatsu

Production Description:

FAG bearings:	3205-BD-2HRS-TVH
Type:	Angular contact ball bearings, double row, lip seals on both sides
Contact angle:	= 30°
Bore diameter:	25 mm
Outer diameter:	52 mm
Depth:	20.6 mm
Dynamic load rating:	22000 N
Static load rating:	15200 N
Fatigue limit load:	1020 N
Limiting speed:	8300 r/min
Reference speed:	12700 r/min
Bearing weight:	0.171 KGS/PC


FAG bearing 3205-BD-2HRS-TVH is sealed by lip seals on both sides. Contact seals are suitable for giving protection against dust, contamination and damp atmospheres. The new design of lip geometry, with axial contact and a dust deflector, has lower friction and thus generates less heat. It allows higher speeds. Contact: sales(at)hzskf.cn

Yakang Bearing Supplies are engaged in distributing Schaeffler FAG/INA angular contact ball bearings.


FAG bearings	d	D	B
	mm	mm	mm
3202-BD-2HRS-TVH	15	35	15,9
3203-BD-2HRS-TVH	17	40	17,5
3204-BD-2HRS-TVH	20	47	20,6
3205-BD-2HRS-TVH	25	52	20,6
3206-BD-2HRS-TVH	30	62	23,8
3207-BD-2HRS-TVH	35	72	27
3208-BD-2HRS-TVH	40	80	30,2
3209-BD-2HRS-TVH	45	85	30,2
3210-BD-2HRS-TVH	50	90	30,2
3211-BD-2HRS-TVH	55	100	33,3
3212-BD-2HRS-TVH	60	110	36,5
3213-BD-2HRS-TVH	65	120	38,1
3214-B-2RSR-TVH	70	125	39,7
3215-B-2RSR-TVH	75	130	41,3
3302-BD-2HRS-TVH	15	42	19
3303-BD-2HRS-TVH	17	47	22,2
3304-BD-2HRS-TVH	20	52	22,2
3305-BD-2HRS-TVH	25	62	25,4
3306-BD-2HRS-TVH	30	72	30,2
3307-BD-2HRS-TVH	35	80	34,9
3308-BD-2HRS-TVH	40	90	36,5
3309-BD-2HRS-TVH
