Product Attribute:
Diameter:297mm
Centering Diameter:108mm
Height:68mm
High-Performance Disc Brakes brand:SK
High-Performance Disc BrakeCertification:ISO 9001 2008
High-Performance Disc Brakes Guarantee:50000-80000kms
High-Performance Disc Brakes Pay Term:TT
High-Performance Disc Brakes Price:Competitive
High-Performance Disc Brak Delivery time:20-30days
High-Performance Disc Brakes Market Type:After Market
Applicationt:
Toyota HILUX
Production Description:
High-Performance Disc Brakes Front and Rear 43512-OK060/435120K070/435120K050 for Japan car
Toyota HILUX
|
Diameter |
297mm |
Height |
68mm |
|
Number of holes |
6 |
Centering Diameter |
108mm |
|
Brake Disc Type |
Vented |
Weight |
6.8kg |
|
Min.Thickness |
23.5mm |
Brake Disc Thickness |
25mm |
Material Requirements :
1. Must meet Grade HT250 for gray iron castings
2. Chemical Composition (Percent)
* Total Carbon: 3.0 - 3.50%
* Silicon: 1.90 - 2.30%
* Manganese: 0.60 - 0.90%
* Phosphorus: 0.12% Max.
* Sulfur: 0.10% Max.
3. Microstructure:
Graphite Structure: Predominantly type A, size 3-5.
Matrix: Pearlistic with max.15 ferrite. Free from chill
4. Physical Properties
Tensile Strength: Min. 200 N/mm
Brinell Hardness: 190 ~ 230
Advantages
1,Tracking And Timely Reply
2,Guaranteed product quallity
3,Satisfactory product price
4,Prompt delivery time
5,Excellent customer service
