Auto Diagnostic Tool MVCI For TOYOTA TIS

Auto Diagnostic Tool MVCI For TOYOTA TIS

Application:  Europe, Asia, Japanese ...

Market Type:  After Market

Packing:  We Use 2 Layers Packing--First Layer Plastic Packaged, Moistureproof, Waterproof; Second Layer, Carton Package Safe.

Samples:  Charge

Sample Price (USD):  115

Maximum Prodcution Capacity:  500

Delivery Time:  Will Send Within 2 Working Days

Place of origin:  China

Unit Price:  USD 115

Price Terms:  FOB

Delivery Port:  Shenzhen

Minimum Order:  1Set/Sets

Product Attribute:

Brand Name:Diagnostic Scanner

Type:Car Diagnostic Scanner diagnostic tool

Function:Auto Diagnostic tool

Applicationt:

Europe, Asia, Japanese vehicles etc

Production Description:



China J2354 ,MVCI tool is a high performance OEM diagnostics and reprogramming interface for TOYOTA TIS,HONDA HDS,and VOLVO DIDA. MVCI device is compatible with Toyota group vehicles like Toyota, Lexus, and Scion over the J1962 DLC3 diagnostic connector. Ideal tool for Toyota group vehicles workshops, everything you need to maintain Toyota, Lexus and Scion vehicles that uses these protocols: K-Line ISO 9141, KWP 2000 ISO 14230-4, SAE J1850 PWM, SAE J1850 VPW, CAN 2.0B ISO 11898, CAN ISO 15765-4
MVCI TOYOTA TIS+HONDA HDS+VOLVO DICE

Software Version TIS: 6.01 HDS: 2.28 VOLVO: V2010
Suitable car brands
Honda, Toyota, Lexus and Volvo

TOYOTA Lexus TIS MVCI interface Features 1.  Fully compatible with Toyota TIS Techstream, HONDA HDS and VOLVO DIDA,3-IN-1
2.  Supports Diagnostics, Reprogramming, Active tests, and key programming
3.  Supports most 1996 and newer Toyota, Lexus, and Scion vehicles with OBDII/DLC3 diagnostics
4.  Fully compatible with SAE J2534
5.  Programmable power supply
6.  Able to apply 5V-24V to OBD pins 6,9,11,12,13,14 or AUX 2.5mm stereo connector
7.  Able to apply GND to OBD pins 6,9,11,12,13,14,15 or AUX 2.5mm stereo connector
8.  RGB status LEDs

MVCI Supported Protocols 1.  K-Line ISO 9141
2.  KWP 2000 ISO 14230-4
3.  SAE J1850 PWM
4.  SAE J1850 VPW
5.  CAN 2.0B ISO 11898
6.  CAN ISO 15765-4

MVCI Parameter
Operating Temperature -20 to 70 °C ( -4 to 158 °F )
Storage Temperature -40 to 85 °C ( -40 to 185 °F )
Diagnostic Interface 16PIN
USB Interface USB 2.0
Power DC 5 V - 36V
Consumption 0.7W
Dimensions 95mm(3.74)L x 49mm(1.93)W x 28mm(1.10)H
Net Weight 85g
Gross Weight 193g

NOTE
1. Your computer must be windows XP system.
2. Please choose area EUROPEAN when you installing the software. Then it will not ask you for activation code.
