Auto Diagnostic Tool Honda Diagnostic System Kit HDS

Product Attribute:

Brand Name:Diagnostic Scanner

Type:Car Diagnostic Scanner diagnostic tool

Function:Auto Diagnostic tool

Applicationt:

Europe, Asia, Japanese vehicles etc

Production Description:

Honda Diagnostic System Kit HDS, HDS Diagnostic functions available for vehicles of HONDA/ACURA from year 1992 to 2007. HDS Test coverage: Dynamical, Body, Chassis, ABS, SRS, Anti-theft, etc. It supports CAN BUS system, and it can re-program the Auto ECU. This HIM is based on PC operation platform.

Language: English/Chinese

Functions supported by Honda/Acura protocols
1. Reading and decoding fault codes from control blocks' memory
2.  Deleting fault codes
3. Displays system's current parameters in digital form
4. Displays system's current parameters in graphical form
5. Combined displaying of data
6.  Management of executive devices
7. Logs keeping - writing and keeping of digital parameters in memory
8. Special functions - changing of permissible settings of blocks, programming etc

Testable system
1. FSI Auto transmission SRS
2. Anti-theft/Anti-restart ABS TRC
3. ESP 4W S TorqueChanger
4. EPS TRC Keyless Go
5. TPMS Control Module Trouble Code
6. Freeze data frame Compositive Motor Assistant SH-AWD

Functions supported by OBD-II protocols
1. Mode $01 - Displays system current parameters in digital form (up to 8 parameters at once.;
2. Mode $02 - Displays parameters of freeze frame;
3. Mode $03 - Reading and decoding of fault codes from control block? memory;
4. Mode $04 - Deleting of fault codes (memory clearing.;
5. Mode $05 - Displays results of oxygen sensors;
6. Mode $06 - Displays results of changeably controlled systems and components;
7. Mode $07 - Displays results of constantly controlled systems and components;
8. Mode $08 - Management of executive devices;
9. Mode $09 - Displays car identification info.

Hardware and software requirements
1 PC or laptop with either Windows 2000 Professional (SP4 or later) or XP (SP1 or later)
2 Hard disk drive with at least 400MB of free space
3 CD-ROM drive (if a high-speed Internet connection is not available)
4 RS232 port required to connect PC to HIM (PC version software only)
5 Monitor capable of displaying in VGA mode or above (1024 x 768 recommended)
6 Internet connection (high-speed connection recommended)

Diagnostic System kit includes
1pc x HIM with OBDII Cable
1pc x DVD
1pc x 3 Pin Cable
1pc x RS232 Cable
