Digital Auto Resistance Tester Car Resistance Simulator ADD2201

Product Attribute:

Type:Engine Analyzer

Applicationt:

all brands

Production Description:

The digital resistance Simulator is mainly used for quick output resistance values, and can be used to simulate and adjust the resistance value. The resistor value will simultaneously be displayed on the LCD screen. There are two kinds of resistance value adjustment method: According to each step 1 10 50 to adjust resistance value. To input the resistance value is a simple operation.

Features of car Resistance Simulator ADD2201:

Enter button: Press the Enter button to select resistance digital input mode, and confirm the input values,Press the enter button for at least 2 seconds, to enter calibration mode

Cancel button: Exit resistance digital input mode

UP and down button: adjust and change resistance value

Display: display the value of resistance output and power indicator

Connect terminal: Connected to the terminal of the sensor

2.Two kinds of operation modes: resistance digital input mode and step adjustment mode

3.Simulate resistance value range:   1001000, step1
                                  100010000,step10
                                   1000020000,step50

4.Power supply: Two R03(size AAA) batteries

5.Support memory and correction of the resistance value: ±5

6.Electric current:  80mAAfter the power is turned off, the current is less than 50uA

7.Supported by low battery alarm and low battery power off automatically. This is to protect the rechargeable battery.

8.Accuracy: 5%

9.Voltage: 3.3V±0.3V

10.Operating temperature -10 to 40

11.Storage temperature: -20 to 60

Applications:

Resistance style sensor signals can be simulated in the vehicle for trouble diagnosis. This allows the sensor to be isolated for circuit testing. This will allow you turn on and off the electronic fan for air conditioning repair trouble
finding etc., Low or high temperature signals, can be produced to test other component reactions.
