Product Attribute:
Type:Engine Analyzer
Applicationt:
all brands
Production Description:
Main technical parameters
Measuring range: 0~1.4Mpa(0~200PSi)
Grade of precision: Grade Four
Weight:1 gram
Screw thread: M 14X1.25, M 18X1.5
The gauge can be used in measuring the pressure of the service medium of liquid, vapor and gas which will not corrode copper-alloys. Because a slip electic resistence transmitter is fixed in the gauge, it can change the measuring value into the electrical, value and send it to the second instrument. then it can realize the concentrated check and remote control. Besides, this gauge can point the pressure on the spot, so it can be used as examine the techniques on the spot.
cylinder pressure gauge Parameter
Place of Origin: |
China (Mainland) |
Brand Name: |
FLB |
Model Number: |
G324 |
|
Packing: |
Color Box |
Type: |
Other |
|
|
cylinder pressure gauge Specifications
Packing Detail: plastic molded storage case with ample space for additional adapters and parts.
SF-60E cylinder pressure gauge
A convenient push-button release valve provides for re-checking cylinder compression without removing the gauge.
1.Uses
Type Cylinder Pressure Gauge is used to test maximum pressure produced by compression stroke in cylinder of gasoline engine.
It shall be used under
ambient air temperature of -40°C~+60°C and relative humidity of not exceeding 90%.
2. Operational principle and structure
Type Cylinder Pressure Gauge consists of pressure gauge, button, quick connector,hose and straight tube. The pressure gauge consists of connector, Bourdon tube, dial plate and indicator. When it is used, compressed gas in cylinder flow into the pressure gauge through rubber stopper or copper connector of measuring part, which brings displacement of free end of the Bourdon tube, and as a result, the indicating needle rotates by means of gear drive to indicate pressure value on the dial plate.
