Product Attribute:
Length:385mm
Width:325mm
Height:370mm
Compressor brand:bock
Delivery time:Bock compressor sent within 3 working days
Bock compressor warranty:1 year
Applicationt:
Yutong, Kinglong, etc, KOREAN Hyundai, Daewoo, JAPANESE Hino, Suzuki, UD, NISSAN, Toyota, etc. EUROPEAN Scania, Caterpillar, Volvo, Benz, etc
Production Description:
BOCK Compressor FK40 655K
Applicated for bus 12M-22M
Condition: brand new bock compressor
Air conditioner BOCK OEM compressor FK40-655K. Special pressure balance bypass prevent lube oil into inside, the efficiency much better. Patented infiltrated ceramic piston ring without gap at joint prolongs the service life.Unitary body cast by Aluminum Alloy with optimum heat transfer.
Specifications
1. Bus model: CHINESE Yutong, Kinglong, etc, KOREAN Hyundai, Daewoo, JAPANESE Hino, Suzuki, UD, NISSAN,Toyota,etc. EUROPEAN Scania, Caterpillar, Volvo, Benz, etc.
2.Offer Compressor for World Famous Bus Manufacturers
3.Own professional bus ac system technical team, offer you professional guide and technical plan.
4. Good quality, 100% original Bock Compressor .
Technical data
Number of cylinders / Bore / Stroke |
4 / 50 mm / 49 mm |
|
Swept volume |
385 cm³ |
|
Displacement (1450/3000 ¹/min) |
33,50 / 69,30 m³/h |
|
Mass moment of inertia |
0,0043 kgm² |
|
Weight |
35 kg |
|
Permissible range of rotation speeds |
500 - 3500 ¹/min |
|
Max. permissible pressure (LP/HP) |
19 / 28 bar |
|
Connection suction line SV |
28 mm - 1 1/8 " |
|
Connection discharge line DV |
22 mm - 7/8 " |
|
Lubrication |
Oil pump |
|
Oil type R134a, R404A, R407C, R507 |
FUCHS Reniso Triton SE 55 |
|
Oil type R22 |
FUCHS Reniso SP 46 |
|
Oil charge |
2,0 Ltr. |
|
Dimensions |
385 / 325 / 370 mm |
|
Length / Width / Height |
|
LP = Low pressure,HP = High pressure |
|
Performance data and operating limits
Performance data and operating limits
R134a Performance data 1450 1/min
Cond. |
Refrigeration Capacity Q0 [W], Power Consumption Pe [kW] |
|
|
Temp. |
Evaporation temperature t0 [°C] |
|
|
tc [°C] |
15 °C |
12.5 °C |
10 °C |
5 °C |
0 °C |
-5°C |
-10°C |
-15°C |
|
|
30 °C |
Q |
54249 |
49594 |
45239 |
37383 |
30586 |
24752 |
19784 |
15587 |
|
|
P |
5.01 |
5.27 |
5.46 |
5.66 |
5.65 |
5.46 |
5.13 |
4.7 |
|
|
40 °C |
Q |
48521 |
44275 |
40310 |
33176 |
27022 |
21753 |
17273 |
13485 |
|
|
P |
7.19 |
7.26 |
7.27 |
7.14 |
6.83 |
6.39 |
5.86 |
5.28 |
|
|
50 °C |
Q |
42621 |
38792 |
35224 |
28825 |
23328 |
18637 |
14657 |
11291 |
|
|
P |
9.11 |
9.01 |
8.85 |
8.42 |
7.86 |
7.21 |
6.5 |
5.79 |
|
|
60 °C |
Q |
36594 |
33188 |
30023 |
24372 |
19545 |
15447 |
|
