Rosemount 3051SFP Wireless Integral Orifice Flow Meter

Product Attribute:

Application temperature:40°C

current :10MA

Size:20inch

Color:Blue

Certification:CC

Cylinder:other

Applicationt:

rosemount

Production Description:

Rosemount  3051SFP Wireless Integral Orifice Flow Meter
The Rosemount 3051SFP Wireless Integral Orifice Flow Meter is a multivariable solution that delivers precise measurements via a secure WirelessHART?network. This best-in-class solution comes with an integral orifice primary element that is provided in a meter run and engineered to facilitate high accuracy of flow measurements in small line sizes (0.5 - 1.5 in. or 15 - 40 mm). The easy installation of this flow meter allows for quick instrumentation of measurement points without the cost of wiring.

Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.

Specifications

DOWNLOAD FULL SPECS
Measurement Type Differential Pressure and Static Pressure
Differential Pressure
Accuracy Up to ±1.05% of flow rate
Stability Up to ±0.15% of Upper Range Limit (URL) for 15 years
Warranty Up to 15-year limited warranty
Rangedown Up to 200:1 (14:1 flow turndown)
Measurement Range Up to 2000 psi (137,89 bar) differential, Up to 3626 psia (250,00 bar) absolute, Up to 3626 psig (250,00 bar) gage
Line Size 0.5 to 1.5 in. (15 to 40 mm)
Output Differential pressure, static pressure, scaled variable
Communication Protocol WirelessHART?
Process Wetted Material 316 SST
Diagnostics Basic Diagnostics
Certifications/Approvals NACE, hazardous location, see full specs for complete list of certifications
Update Rate 1 sec. to 60 min., user selectable
Power Module Life Up to 10-year life, field replaceable (order separately)
Wireless Range Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km)




Features

WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy
Primary element integrated in a meter run for ease of installation
Orifice plate suitable for small line sizes 0.5- 1.5 in. (15 - 40 mm) for flow measurement accuracy and repeatability
All-welded, resilient SuperModule? sensor offers best-in-class accuracy in harsh environments and applications
Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation
Flowmeter technology eliminates unnecessary pipe penetrations for an integrated, trouble-free solution
Self-centering orifice plate prevents installation error to ensure best-possible performance
SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
Easy installation enables quick instrumentation of measurement points without the cost of wiring
