Rosemount 3051SFP Integral Orifice Flow Meter

Product Attribute:

Voltage:12v

Type:Water temperature gauge

Weight :5kg

Material:other

Applicationt:

rosemount

Production Description:

Rosemount  3051SFP Integral Orifice Flow Meter
The Rosemount 3051SFP Integral Orifice Flow Meter is a no-equal multivariable device customized with an integral orifice primary element. This meter run assembly provides easy installation and is engineered to facilitate highly accurate flow measurement in small line sizes (0.5 - 1.5 in. or 15 - 40 mm). This device is also engineered with built-in flow calculations for fully compensated mass flow measurements.



Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.
Specifications

DOWNLOAD FULL SPECS
Measurement Type Differential Pressure, Static Pressure, Process Temperature
 Differential Pressure and Static Pressure
 Differential Pressure and Process Temperature
 Differential Pressure
Accuracy Up to ±1.05% of flow rate
Stability Up to ±0.15% of Upper Range Limit (URL) for 15 years
Warranty Up to 15-year limited warranty
Rangedown Up to 200:1 (14:1 flow turndown)
Measurement Range Up to 2000 psi (137,89 bar) differential, Up to 3626 psi (250,00 bar) static
Line Size 0.5 to 1.5 in. (15 to 40 mm)
Output Differential pressure, static pressure, process temperature, scaled variable, mass flow, volumetric flow, energy flow
Communication Protocol 4-20 mA HART?, WirelessHART?, FOUNDATION? Fieldbus
Process Wetted Material 316 SST
Diagnostics Basic Diagnostics, Power Advisory Diagnostics, Advanced Diagnostics
Certifications/Approvals SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications


Features

Designed with built-in flow calculations for direct reporting of fully-compensated mass flow
Advanced diagnostics provide diagnostic coverage to detect abnormal process conditions and electrical loop issues
Primary element integrated in a meter run for ease of installation
Suitable for small line sizes 0.5- 1.5 in. (15 - 40 mm) for optimal flow measurement accuracy and repeatability
Callendar-Van Dusen sensor matching improves temperature accuracy enabling best-in-class flow calculations
Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy
All-welded, SuperModule? design offers industry-leading accuracy in harsh environments and applications
Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation
Flowmeter technology eliminates unnecessary pipe penetrations for an integrated, trouble-free solution
SIL 2/3 certified to IEC 61508 (via 3rd party) and prior-use certificate of FMEDA data for safety installations
