Rosemount 3051SFA Wireless Annubar Flow Meter

Product Attribute:

Voltage:12v

Type:Water temperature gauge

Weight :5kg

Material:other

Applicationt:

ROSEMOUNT

Production Description:

Rosemount 3051SFA Wireless Annubar  Flow Meter
The Rosemount 3051SFA Wireless Annubar Flow Meter is a cost-effective, best-in-class MultiVariable solution that provides measurements via a secure WirelessHART? network. This flow meter delivers direct variable measurements without the cost of wiring and is built with a patented averaging pitot tube designed for optimal accuracy over a wide flow range. This T-shaped Annubar sensor also maintains a small profile in the pipe for reduced permanent pressure loss and increased energy savings.




Our services:
1.We can provide 1-year warranty.
2.The goods will be shipped out within about 3-5 working days.
3.Shipping methods: air by DHL/UPS/EMS/Fedex...
4.Small orders can be all accepted.
5.Contact us any time when you feel free.

Specifications

DOWNLOAD FULL SPECS
Measurement Type Differential Pressure and Static Pressure
Differential Pressure
Accuracy Up to ±0.80% of flow rate
Stability Up to ±0.15% of Upper Range Limit (URL) for 15 years
Warranty Up to 15-year limited warranty
Rangedown Up to 200:1 (14:1 flow turndown)
Measurement Range Up to 2000 psi (137,89 bar) differential, Up to 3626 psia (250,00 bar) absolute, Up to 3626 psig (250,00 bar) gage
Line Size 2 to 96 in. (50 to 2440 mm)
Output Differential pressure, static pressure, scaled variable
Communication Protocol WirelessHART?
Process Wetted Material 316 SST, Alloy C-276
Diagnostics Basic Diagnostics
Certifications/Approvals NACE, hazardous location, see full specs for complete list of certifications
Update Rate 1 sec. to 60 min., user selectable
Power Module Life Up to 10-year life, field replaceable (order separately)
Wireless Range Long range (225 m), extended range (800 m), remote (225 m) and high-gain remote (1 km)





Features

WirelessHART? technology is secure, cost-effective and delivers >99% data reliability
Ultra for Flow performance class enables optimized flow measurement with a ±0.04% of reading accuracy
Patented T-shape sensor creates a fixed separation point for DP signal improvement over a wider flow rate
All-welded, resilient SuperModule? sensor offers best-in-class accuracy in harsh environments and applications
Flowmeters come fully configured, leak-tested and ready to install right out of the box for fast installation
Sensor stagnation zone positioned to reduce noise, measurement inaccuracies and keeps particulates from clogging
T-shape sensor design offers very low permanent pressure loss
SmartPower? module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
Easy installation enables quick instrumentation of measurement points without the cost of wiring
Easy installation enables quick instrumentation of measurement points without the cost of wiring
